McIntosh C1000

46
C167 CAP ELECT 47UF 35V 066446
C168 CAP MONO 22PF 200V 10% NPO 061339
C177 CAP MONO .1UF 50V 20% Z5U 061346
D3 DIODE SILICON 070174
D4 DIODE SILICON 070174
D7 DIODE SILICON 070174
D8 DIODE SILICON 070174
D9 DIODE SILICON 070174
D10 DIODE SILICON 070174
DS1 LED GREEN 3MM HI INTENSITY 058172
(DS1) LED SPACER .125 THK 017672
DS2 LED GREEN 3MM HI INTENSITY 058172
(DS2) LED SPACER .125 THK 017672
GP1 BRACKET PCB CARD MOUNTING 003611
GP2 BRACKET PCB CARD MOUNTING 003611
J1 JACK PHONO GOLD 117862
J2 JACK PHONO GOLD 117862
J3 JACK PHONO GOLD 117862
J4 JACK PHONO GOLD 117862
J5 JACK PHONO GOLD 117862
J6 JACK PHONO GOLD 117862
J7 JACK PHONO GOLD 117862
J8 CONN 12 PIN FFC 117720
J9 HEADER SHROUDED 2 ROW 26 PIN V 117870
J10 HEADER 2 PIN LATCHING 117766
J11 CONN 12 PIN FFC 117720
J12 CONN 12 PIN FFC 117720
J13 HEADER 2 PIN LATCHING 117766
J14 CONN 12 PIN FFC 117720
J15 CONN 12 PIN FFC 117720
J16 CONN 12 PIN FFC 117720
J17 CONN 12 PIN FFC 117720
J18 HEADER 2 PIN LATCHING 117766
K1 RELAY REED FORM 1A 5V 500 OHMS 087050
K2 RELAY REED FORM 1A 5V 500 OHMS 087050
K3 RELAY REED FORM 1A 5V 500 OHMS 087050
K4 RELAY REED FORM 1A 5V 500 OHMS 087050
K5 RELAY REED FORM 1C 5V 125 OHMS 087056
K6 RELAY REED FORM 1A 5V 500 OHMS 087050
K7 RELAY REED FORM 1A 5V 500 OHMS 087050
K8 RELAY REED FORM 1A 5V 500 OHMS 087050
K9 RELAY REED FORM 1A 5V 500 OHMS 087050
K10 RELAY REED FORM 1A 5V 500 OHMS 087050
K11 RELAY REED FORM 1A 5V 500 OHMS 087050
K12 RELAY REED FORM 1A 5V 500 OHMS 087050
K13 RELAY REED FORM 1A 5V 500 OHMS 087050
K14 RELAY REED FORM 1A 5V 500 OHMS 087050
K15 RELAY REED FORM 1C 5V 125 OHMS 087056
K16 RELAY REED FORM 1C 5V 125 OHMS 087056
K17 RELAY REED FORM 1C 5V 125 OHMS 087056
K18 RELAY REED FORM 1C 5V 125 OHMS 087056
K19 RELAY REED FORM 1A 5V 500 OHMS 087050
K20 RELAY REED FORM 1A 5V 500 OHMS 087050
K21 RELAY REED FORM 1A 5V 500 OHMS 087050
K22 RELAY REED FORM 1A 5V 500 OHMS 087050
K23 RELAY REED FORM 1A 5V 500 OHMS 087050
K24 RELAY REED FORM 1A 5V 500 OHMS 087050
K25 RELAY REED FORM 1A 5V 500 OHMS 087050
MC1 ASSEMBLY PCB PHONO MC 050104
RIVET 1/8 X 3/16 STEEL 108011
PCB1 PC BD MAIN L 129542
Q1 TRANSISTOR NPN 2K/REEL 132317
Q2 TRANSISTOR SI NPN 25V 132257
Q3 TRANSISTOR SI NPN 25V 132257
Q4 TRANSISTOR PNP 132304
Q5 TRANSISTOR PNP 132304
Q6 TRANSISTOR N JFET 132319
Q7 TRANSISTOR PNP 132304
Q8 TRANSISTOR N JFET 132319
Q9 TRANSISTOR PNP 132304
Q10 TRANSISTOR N JFET 132319
Q11 TRANSISTOR PNP 132304
Q12 TRANSISTOR N JFET 132319
Q14 TRANSISTOR NPN 2K/REEL 132317
Q15 TRANSISTOR NPN 2K/REEL 132317
R1 RES MF 100 OHM 1% 1/4W 144568
R2 RES MF 4.75K 1% 1/4W 144520
R3 RES MF 2.21K 1% 1/4W 144584
R4 RES MF 47.5 OHM 1% 1/4W 144642
R5 RES MF 47.5 OHM 1% 1/4W 144642
R6 RES MF 1.82K 1% 1/4W 144582
R7 RES MF 1.82K 1% 1/4W 144582
R8 RES MF 2.21K 1% 1/4W 144584
R9 RES MF 6.49K .5% 1/4W 144617
R10 RES MF 20K 1% 1/4W 144524
R11 RES MF 20K 1% 1/4W 144524
R12 RES MF 22.1K 1% 1/4W 144564
R13 RES MF 22.1K 1% 1/4W 144564
R14 RES MET OX 430 OHM 5% .5W 137101
R15 RES MET OX 430 OHM 5% .5W 137101
R22 RES MF 267K 1% 1/4W 144532
R27 RES MF 267K 1% 1/4W 144532
R28 RES MF 267K 1% 1/4W 144532
R29 RES MF 182 OHM 1/4W 1% 144579
R30 RES MF 182 OHM 1/4W 1% 144579
R31 RES MF 182 OHM 1/4W 1% 144579
R36 RES MF 100K 1% 1/4W 144528
R37 RES MF 1K 1% 1/4W 144513
R38 RES MF 1K 1% 1/4W 144513
R39 RES MF 1K 1% 1/4W 144513
R40 RES MF 1K 1% 1/4W 144513
R42 RES MF 1K 1% 1/4W 144513
R43 RES MF 1K 1% 1/4W 144513
R44 RES MF 4.75K 1% 1/4W 144520
R45 RES MF 4.75K 1% 1/4W 144520
R46 RES MF 4.75K 1% 1/4W 144520
R47 RES MF 4.75K 1% 1/4W 144520
R48 RES MF 4.75K 1% 1/4W 144520
R49 RES MF 4.75K 1% 1/4W 144520
R50 RES MF 100K 1% 1/4W 144528
R51 RES MF 33.2K 1% 1/4W 144694
R52 RES MF 1K 1% 1/4W 144513
R53 RES MF 4.99K 1% 1/4W 144521
R54 RES MF 4.99K 1% 1/4W 144521
R55 RES MF 2.21 OHM 1/4W 1% 144607
R56 RES MF 2.21 OHM 1/4W 1% 144607
R59 RES MF 47.5K 1% 1/4W 144526
R60 RES MF 47.5K 1% 1/4W 144526
R61 RES MF 47.5K 1% 1/4W 144526
R62 RES MF 47.5K 1% 1/4W 144526
R63 RES MF 10 OHM 1% 1/4W 144553
MAIN LEFT PCB 050109 (Cont’d)
Ref. No. Description Part No.
PARTS LIST Cont’d
Ref. No. Description Part No.
