McIntosh C1000 Service Manual

TUBE PREAMPLIFIER
C1000
MAIN LEFT PCB 050109
Ref. No. Description Part No.
PARTS LIST
45
C1 CAP ELECT 220UF 25V 066507
C2 CAP ELECT 47UF 35V 066446
C3 CAP ELECT 220UF 25V 066507
C4 CAP MONO 100PF 100V 10% NPO 061341
C5 CAP MONO 100PF 100V 10% NPO 061341
C6 CAP ELECT 4.7UF 50V 066512
C7 CAP ELECT 10UF 50V 066445
C8 CAP ELECT 10UF 50V 066445
C16 CAP ELECT 47UF 35V 066446
C23 CAP ELECT 10UF 16V 066580
C24 CAP ELECT 10UF 16V 066580
C25 CAP ELECT 10UF 16V 066580
C26 CAP ELECT 10UF 16V 066580
C32 CAP MONO .1UF 50V 20% Z5U 061346
C33 CAP MONO .1UF 50V 20% Z5U 061346
C34 DIODE SIL 400PIV @ 1.5A 070031
C35 CAP MONO .1UF 50V 20% Z5U 061346
C37 CAP ELECT 4.7UF 50V 066512
C38 CAP MONO 220PF 200V 10% NPO 061342
C39 CAP ELECT 10UF 50V 066445
C40 CAP MONO 100PF 100V 10% NPO 061341
C41 CAP MONO 100PF 100V 10% NPO 061341
C42 CAP MONO 22PF 200V 10% NPO 061339
C43 CAP MONO 22PF 200V 10% NPO 061339
C44 CAP ELECT 10UF 16V 066580
C45 CAP ELECT 10UF 16V 066580
C46 CAP ELECT 10UF 16V 066580
C47 CAP ELECT 10UF 16V 066580
C48 CAP ELECT 10UF 100VDC 066462
C50 CAP MONO .1UF 50V 20% Z5U 061346
C51 CAP MONO .1UF 50V 20% Z5U 061346
C54 CAP ELECT 10UF 50V 066445
C55 CAP ELECT 10UF 50V 066445
C56 CAP ELECT 10UF 50V 066445
C57 CAP ELECT 10UF 50V 066445
C58 CAP MONO 100PF 100V 10% NPO 061341
C59 CAP MONO 100PF 100V 10% NPO 061341
C60 CAP MONO 100PF 100V 10% NPO 061341
C61 CAP MONO 100PF 100V 10% NPO 061341
C62 CAP MONO 22PF 200V 10% NPO 061339
C63 CAP MONO 22PF 200V 10% NPO 061339
C65 CAP ELECT 10UF 100VDC 066462
C66 CAP MONO .1UF 50V 20% Z5U 061346
C69 CAP MONO .1UF 50V 20% Z5U 061346
C70 CAP ELECT 10UF 50V 066445
C71 CAP ELECT 10UF 50V 066445
C72 CAP MONO .1UF 50V 20% Z5U 061346
C73 CAP MONO .1UF 50V 20% Z5U 061346
C76 CAP ELECT 10UF 100VDC 066462
C78 CAP MONO 22PF 200V 10% NPO 061339
C79 CAP MONO 22PF 200V 10% NPO 061339
C80 CAP MONO 22PF 200V 10% NPO 061339
C81 CAP MONO 100PF 100V 10% NPO 061341
C82 CAP ELECT 10UF 100VDC 066462
C83 CAP MONO .1UF 50V 20% Z5U 061346
C84 CAP MONO .1UF 50V 20% Z5U 061346
C85 CAP MONO 100PF 100V 10% NPO 061341
C86 CAP ELECT 10UF 50V 066445
C87 CAP ELECT 10UF 16V 066580
C88 CAP ELECT 10UF 50V 066445
C89 CAP ELECT 10UF 50V 066445
C90 CAP ELECT 10UF 50V 066445
C91 CAP MONO .1UF 50V 20% Z5U 061346
C92 CAP MONO 100PF 100V 10% NPO 061341
C93 CAP MONO 100PF 100V 10% NPO 061341
C94 CAP MONO 100PF 100V 10% NPO 061341
C95 CAP MONO 100PF 100V 10% NPO 061341
C96 CAP ELECT 10UF 50V 066445
C97 CAP MONO 220PF 200V 10% NPO 061342
C98 CAP MONO 22PF 200V 10% NPO 061339
C99 CAP MONO 22PF 200V 10% NPO 061339
C100 CAP ELECT 10UF 100VDC 066462
C102 CAP MONO .1UF 50V 20% Z5U 061346
C103 CAP MONO .1UF 50V 20% Z5U 061346
C106 CAP ELECT 47UF 35V 066446
C107 CAP ELECT 47UF 35V 066446
C108 CAP ELECT 10UF 250V 066558
C111 CAP MONO .1UF 50V 20% Z5U 061346
C112 CAP ELECT 10UF 50V 066445
C113 CAP MONO .1UF 50V 20% Z5U 061346
C114 CAP POLYPROP 0.22UF 400V 20% 064438
C115 CAP POLYPROP 0.22UF 400V 20% 064438
C116 CAP MONO .1UF 50V 20% Z5U 061346
C117 CAP ELECT 10UF 50V 066445
C118 CAP MONO 100PF 100V 10% NPO 061341
C119 CAP MONO 100PF 100V 10% NPO 061341
C120 CAP MONO 22PF 200V 10% NPO 061339
C121 CAP MONO 22PF 200V 10% NPO 061339
C122 CAP POLY .047UF 10% 1000VDC 064434
C123 CAP POLY .047UF 10% 1000VDC 064434
C124 CAP ELECT 22UF 100V 066574
C125 CAP MONO 22PF 200V 10% NPO 061339
C126 CAP MONO 22PF 200V 10% NPO 061339
C127 CAP ELECT 10UF 100VDC 066462
C129 CAP MONO .1UF 50V 20% Z5U 061346
C130 CAP MONO .1UF 50V 20% Z5U 061346
C133 CAP MONO 220PF 200V 10% NPO 061342
C134 CAP MONO .1UF 50V 20% Z5U 061346
C136 CAP MONO 1000PF 50V 10% NPO 061344
C137 CAP ELECT 220UF 25V 066507
C138 CAP ELECT 220UF 25V 066507
C139 CAP MONO 1000PF 50V 10% NPO 061344
C141 CAP MONO 1000PF 50V 10% NPO 061344
C143 CAP MONO 1000PF 50V 10% NPO 061344
C145 CAP MONO 22PF 200V 10% NPO 061339
C146 CAP MONO 22PF 200V 10% NPO 061339
C147 CAP ELECT 10UF 100VDC 066462
C149 CAP MONO .1UF 50V 20% Z5U 061346
C150 CAP MONO .1UF 50V 20% Z5U 061346
C153 CAP ELECT 220UF 25V 066507
C154 CAP ELECT 220UF 25V 066507
C155 CAP MONO 22PF 200V 10% NPO 061339
C156 CAP ELECT 10UF 100VDC 066462
C157 CAP MONO .1UF 50V 20% Z5U 061346
C158 CAP MONO .1UF 50V 20% Z5U 061346
C159 CAP MONO 22PF 200V 10% NPO 061339
C160 CAP ELECT 10UF 100VDC 066462
C161 CAP ELECT 100UF 25V 066573
C162 CAP MONO .1UF 50V 20% Z5U 061346
C163 CAP MONO .1UF 50V 20% Z5U 061346
C164 CAP MONO 22PF 200V 10% NPO 061339
C165 CAP MONO .1UF 50V 20% Z5U 061346
C166 CAP MONO .1UF 50V 20% Z5U 061346
Ref. No. Description Part No.

