McIntosh C12000 Controller

17
WLAN ANT 1
WLAN ANT 2
McINTOSH LABORATORY, INC.,
BINGHAMTON, NY
MCD550
SACD/CD PLAYER
HANDCRAFTED IN USA WITH US AND IMPORTED PARTS
Digital Audio Player
Turntable with Moving Coil Cartridge
AM/ FM Tu ner
Media Bridge
SACD/CD Player
From C12000 Controller
Left Output
From C12000 Controller
Right Output
Connection Legend:
Data Cable* Digital Signal Cable
Sensor/Keypad Cable Ground Wire
Power Control Cable* Audio Signal Cable
Loudspeaker Cable
* 2 conductor shielded with 1/8 inch stereo mini phone plug on each end.
