19
Preamplifier Connection Diagram - Passthru Connections
A/V Processor
Power Amplifier (Left Front Channel) - Main Room
(Partial View)
Power Amplifier (Right Front Channel) - Main Room
(Partial View)
Connection Legend:
Data Cable* Digital Signal Cable
Sensor/Keypad Cable Ground Wire
Power Control Cable* Audio Signal Cable
Loudspeaker Cable
* 2 conductor shielded with 1/8 inch stereo mini phone plug on each end.
