McIntosh Labs: C200
Digital IR Remote Control
C200 Controller Dimensions: 17.5W x 5.37H x 20D (26 lbs.)
C200 Preamplifier Dimensions: 17.5W x 5.37H x 20D (20.5 lbs)
Separate Electronic
Regulators for Each Pre-
amplifier Section
Type of Volume Control VRV
Programmable Source Trim
Independent Listen and
Record Selection
Electromagnetic Switching
Low-Noise 1% Metal Film
Resistors
Glass Front Panel with
Illuminated Nomenclature
Connector for External IR
Sensor
Control Data Outputs
Dual-Chassis Design
Ultra-Low Distortion
Discrete Output Circuit
Extra-Wide Dynamic Range
Shielded Power Transformer
Polyester Coupling
Capacitors
Ultra-precision (.5%) metal
film resistors and 1%
polypropylene capacitors for
phono equalization
Dual Processor Loops
Balanced Input(s)
Phono Input MM/MC Phono Inputs
Balanced Output(s)
Type of Amplifier Solid State
Headphone Jack
Gold Plated Terminals
Frequency Response 10 Hz to 40 KHz +0 / -0.5 dB
Rated Output Voltage 2.5 Vrms
Maximum Unclipped Output 25 Vrms
Output Impedance 100 ohms balanced / 50 ohms unbalanced
Total Harmonic Distortion 0.002 %
Input Sensitivity 450 mV
Maximum Input Signal 5 v
Signal to Noise Ratio 98 dB
Input Impedence 44k ohms
Warranty (parts) 36 month(s)
Warranty (labor) 36 month(s)
Dimensions
3.375 in. H x 17.5 in. W x 20 in. D (13.7 cm. H x 44.5 cm. W x 50.8 cm.
D)
Weight 40.4 lbs. (18.4 kg.)
