McIntosh C2500

82
PARTS LIST cont’d.
CONTROL PCB 751457 (Cont’d.)
Ref No. Description Part No.
3
Ref No. Description Part No.
4
AUDIO PCB 751458
R203 RES SMD0805 22.1K 1/8W 1% 145012
R204 RES SMD0805 22.1K 1/8W 1% 145012
R205 RES SMD0805 22.1K 1/8W 1% 145012
R206 RES SMD0805 22.1K 1/8W 1% 145012
R207 RES SMD0805 22.1K 1/8W 1% 145012
R208 RES SMD0805 22.1K 1/8W 1% 145012
R209 RES SMD0805 22.1K 1/8W 1% 145012
R210 RES SMD0805 22.1K 1/8W 1% 145012
R211 RES SMD0805 22.1 1/8W 1% 145003
R212 RES SMD0805 22.1 1/8W 1% 145003
R215 RES SMD0805 22.1 1/8W 1% 145003
R217 RES SMD0805 22.1 1/8W 1% 145003
R218 RES SMD0805 47.5K 1/8W 1% 145013
R219 RES SMD0805 22.1 1/8W 1% 145003
R220 RES SMD0805 22.1K 1/8W 1% 145012
R221 RES SMD0805 150 1/8W 1% 145019
R222 RES SMD0805 22.1K 1/8W 1% 145012
R223 RES SMD0805 150 1/8W 1% 145019
R224 RES SMD0805 22.1K 1/8W 1% 145012
R225 RES SMD0805 150 1/8W 1% 145019
R226 RES SMD0805 22.1K 1/8W 1% 145012
R231 RES SMD0805 22.1 1/8W 1% 145003
R232 RES SMD0805 22.1 1/8W 1% 145003
R233 RES SMD0805 22.1 1/8W 1% 145003
R234 RES SMD0805 22.1 1/8W 1% 145003
R235 RES SMD0805 22.1 1/8W 1% 145003
R236 RES SMD0805 10K 1/8W 1% 145010
R237 RES SMD0805 22.1K 1/8W 1% 145012
R238 RES SMD0805 10K 1/8W 1% 145010
R239 RES SMD0805 47.5K 1/8W 1% 145013
R240 RES SMD0805 22.1 1/8W 1% 145003
R241 RES SMD0805 22.1 1/8W 1% 145003
R242 RES SMD0805 22.1 1/8W 1% 145003
R246 RES SMD0805 0 1/8W 0% 145016
R247 RES SMD0805 0 1/8W 0% 145016
R248 RES SMD0805 10 1/8W 1% 145017
R250 RES SMD0805 0 1/8W 0% 145016
R251 RES SMD0805 22.1K 1/8W 1% 145012
R252 RES SMD0805 22.1 1/8W 1% 145003
R274 RES SMD0805 1K 1/8W 1% 145007
S1 SWITCH SLIDE DPDT 148076
SW1 SWTCH TACT 1.96N 5.9 X 6MM SMD 150071
SW2 SWTCH TACT 1.96N 5.9 X 6MM SMD 150071
U1 IC SINGLE 2-INPUT AND GATE SMD 133502
U3 IC:MICRO 32-BIT ARM7 SMD 133635
U4 IC SINGLE 2-INPUT AND GATE SMD 133552
U5 IC SINGLE 2-INPUT AND GATE SMD 133552
U6 REG VAR 1.24-26 1A SMD 133717
U7 IC I2C BUS REPEATER SMD 133769
U9 REG NEG ADJ 1A ENA SMD 133731
U10 REG VAR 1.24-26 1A SMD 133717
U11 REG VAR 1.24-26 1A SMD 133717
U12 IC SINGLE NAND SCHMITT SMD 133724
U13 REG VAR 1.24-26 1A SMD 133717
U14 REG VAR 1.24-26 1A SMD 133717
U15 IC SINGLE NAND SCHMITT SMD 133724
U16 IC SINGLE 2-INPUT AND GATE SMD 133502
U17 IC SINGLE 2-INPUT AND GATE SMD 133502
U18 IC 8 BIT DRIVER SMD 133461
U20 IC EEPROM 256K BITS 3.3V SMD 133709
U21 IC SINGLE 2 INPUT OR GATE SMD 133700
U22 IC SNGLE 2-INPUT NAND GATE SMD 133501
U23 IC SINGLE 2-INPUT AND GATE SMD 133552
U24 IC SINGLE 2-INPUT AND GATE SMD 133502
U25 IC SINGLE 2-INPUT AND GATE SMD 133502
U26 IC SINGLE NAND SCHMITT SMD 133724
U27 IC SINGLE NAND SCHMITT SMD 133724
U28 IC 8 BIT DRIVER SMD 133461
U29 REG VAR 1.24-26 1A SMD 133717
U30 IC 8 BIT DRIVER SMD 133461
U31 IC I2C BUS REPEATER SMD 133769
U32 IC I2C BUS REPEATER SMD 133769
U34 IC SINGLE 2-INPUT AND GATE SMD 133552
U35 IC SINGLE 2-INPUT AND GATE SMD 133552
U36 IC SINGLE 2-INPUT AND GATE SMD 133552
U37 IC DUAL RS232 3V W/SHUTDWN SMD 133707
U38 IC SINGLE 2-INPUT AND GATE SMD 133552
Y1 CRYSTAL 18.432000MHZ 20PF SMD 180065
FIRMWARE V1.00 C2500 230039
ASSY SMD CONTROL 710173
C1 CAP 100PF 50V SMD0805 061316
C2 CAP 100PF 50V SMD0805 061316
C3 CAP 1000PF 50V SMD0805 061317
C4 CAP 1000PF 50V SMD0805 061317
C5 CAP 1000PF 50V SMD0805 061317
C6 CAP 1000PF 50V SMD0805 061317
C7 CAP ELECT 1000UF 25V 066513
C8 CAP ELECT 1000UF 25V 066513
C9 CAP ELECT 1000UF 25V 066513
C10 CAP ELECT 1000UF 25V 066513
C11 CAP MONO .1UF 50V 20% X7R SMD0805 061365
C12 CAP MPF 0.0033UF 5% 63VDC 064455
C13 CAP MPF 0.0033UF 5% 63VDC 064455
C14 CAP 22PF 200V 10% NPO SMD0805 061367
C15 CAP 22PF 200V 10% NPO SMD0805 061367
C16 CAP MONO .1UF 50V 20% X7R SMD0805 061365
C17 CAP MONO .1UF 50V 20% X7R SMD0805 061365
C18 CAP MONO .1UF 50V 20% X7R SMD0805 061365
C19 CAP MONO .1UF 50V 20% X7R SMD0805 061365
C20 CAP ELECT 100UF 25V 066573
C21 CAP ELECT 100UF 25V 066573
C38 CAP ELECT 10UF 16V 4X5 CASE T&R 066580
C39 CAP ELECT 10UF 16V 4X5 CASE T&R 066580
C40 CAP ELECT 10UF 16V 4X5 CASE T&R 066580
C41 CAP ELECT 10UF 16V 4X5 CASE T&R 066580
C42 CAP ELECT 10UF 16V 4X5 CASE T&R 066580
C43 CAP ELECT 10UF 16V 4X5 CASE T&R 066580
C44 CAP ELECT 10UF 16V 4X5 CASE T&R 066580
C45 CAP ELECT 10UF 16V 4X5 CASE T&R 066580
C48 CAP ELECT 10UF 50V 066445
C49 CAP ELECT 10UF 50V 066445
C50 CAP ELECT 10UF 50V 066445
C51 CAP ELECT 10UF 50V 066445
C52 CAP 100PF 50V SMD0805 061316
C53 CAP 100PF 50V SMD0805 061316
C62 CAP 100PF 50V SMD0805 061316
