C2500
85
PARTS LIST cont’d.
AUDIO PCB 751458 (Cont’d.)
Ref No. Description Part No.
4
Ref No. Description Part No.
K21 RELAY REED SPST-NO 5V 1.2A 087078
K22 RELAY REED SPST-NO 5V 1.2A 087078
K23 RELAY REED SPST-NO 5V 1.2A 087078
K24 RELAY REED SPST-NO 5V 1.2A 087078
K25 RELAY REED SPST-NO 5V 1.2A 087078
K26 RELAY REED SPST-NO 5V 1.2A 087078
K27 RELAY REED SPST-NO 5V 1.2A 087078
K28 RELAY REED SPST-NO 5V 1.2A 087078
K29 RELAY REED SPST-NO 5V 1.2A 087078
K30 RELAY REED SPST-NO 5V 1.2A 087078
K31 RELAY REED SPST-NO 5V 1.2A 087078
K32 RELAY REED SPST-NO 5V 1.2A 087078
K33 RELAY REED SPST-NO 5V 1.2A 087078
K34 RELAY REED SPST-NO 5V 1.2A 087078
K35 RELAY REED SPST-NO 5V 1.2A 087078
K36 RELAY REED SPST-NO 5V 1.2A 087078
K37 RELAY REED FORM 1C 5V 125 OHM 087056
K38 RELAY REED SPST-NO 5V 1.2A 087078
K39 RELAY REED SPST-NO 5V 1.2A 087078
K40 RELAY REED SPST-NO 5V 1.2A 087078
K41 RELAY REED FORM 1C 5V 125 OHM 087056
K42 RELAY REED SPST-NO 5V 1.2A 087078
K43 RELAY REED SPST-NO 5V 1.2A 087078
K44 RELAY REED SPST-NO 5V 1.2A 087078
K45 RELAY REED SPST-NO 5V 1.2A 087078
K46 RELAY REED SPST-NO 5V 1.2A 087078
K47 RELAY REED SPST-NO 5V 1.2A 087078
K48 RELAY REED SPST-NO 5V 1.2A 087078
K49 RELAY REED SPST-NO 5V 1.2A 087078
PCB1 PC BD AUDIO 130178
Q1 TRANSISTOR NPN 2SC4694 SMD 132336
Q2 TRANSISTOR NPN 2SC4694 SMD 132336
Q3 TRANSISTOR NPN 2SC4694 SMD 132336
Q4 TRANSISTOR NPN 2SC4694 SMD 132336
Q5 TRANSISTOR NPN 2SC4694 SMD 132336
Q6 TRANSISTOR NPN 2SC4694 SMD 132336
Q7 TRANSISTOR NPN 2SC4694 SMD 132336
Q8 TRANSISTOR NPN 2SC4694 SMD 132336
Q9 TRANSISTOR PNP 60V A55 SMD 132334
Q10 TRANSISTOR PNP 60V A55 SMD 132334
Q11 TRANSISTOR NPN A05 SMD 132333
Q12 TRANSISTOR NPN A05 SMD 132333
Q13 TRANSISTOR PNP 60V A55 SMD 132334
Q14 TRANSISTOR PNP 60V A55 SMD 132334
Q15 TRANSISTOR NPN A05 SMD 132333
Q16 TRANSISTOR NPN A05 SMD 132333
Q17 TRANSISTOR PNP 60V A55 SMD 132334
Q18 TRANSISTOR PNP 60V A55 SMD 132334
Q19 TRANSISTOR NPN A05 SMD 132333
Q20 TRANSISTOR NPN A05 SMD 132333
Q21 TRANSISTOR PNP 60V A55 SMD 132334
Q22 TRANSISTOR PNP 60V A55 SMD 132334
Q23 TRANSISTOR NPN A05 SMD 132333
Q24 TRANSISTOR NPN A05 SMD 132333
Q25 TRANSISTOR PNP 60V A55 SMD 132334
Q26 TRANSISTOR PNP 60V A55 SMD 132334
Q27 TRANSISTOR NPN A05 SMD 132333
Q28 TRANSISTOR NPN A05 SMD 132333
Q29 TRANSISTOR PCH 60V J174 132320
Q30 TRANSISTOR PCH 60V J174 132320
Q31 TRANSISTOR PCH 60V J174 132320
Q32 TRANSISTOR PCH 60V J174 132320
Q33 TRANSISTOR PCH 60V J174 132320
Q34 TRANSISTOR PCH 60V J174 132320
Q35 TRANSISTOR PCH 60V J174 132320
Q36 TRANSISTOR PCH 60V J174 132320
Q37 TRANSISTOR NPN A05 SMD 132333
Q38 TRANSISTOR NPN A05 SMD 132333
Q39 TRANSISTOR NPN A05 SMD 132333
Q40 TRANSISTOR NPN A05 SMD 132333
Q41 TRANSISTOR NPN A05 SMD 132333
Q42 TRANSISTOR NPN A05 SMD 132333
Q43 TRANSISTOR NPN A05 SMD 132333
Q44 TRANSISTOR NPN A05 SMD 132333
Q45 TRANSISTOR NPN A05 SMD 132333
Q46 TRANSISTOR NPN A05 SMD 132333
Q47 TRANSISTOR NPN A05 SMD 132333
Q48 TRANSISTOR NPN A05 SMD 132333
Q49 TRANSISTOR NPN 2SC5994 SMD 132341
Q50 TRANSISTOR PNP SMD 132340
Q51 TRANSISTOR NPN 2SC5994 SMD 132341
Q52 TRANSISTOR PNP SMD 132340
Q53 TRANSISTOR NPN A05 SMD 132333
Q54 TRANSISTOR NPN A05 SMD 132333
Q55 TRANSISTOR NPN A05 SMD 132333
Q56 TRANSISTOR NPN A05 SMD 132333
Q57 TRANSISTOR NPN A05 SMD 132333
R1 RES MF 1K 1% 1/4W 144513
R2 RES MF 1K 1% 1/4W 144513
R3 RES MF 110 OHM 1% 1/4W 144664
R4 RES MF 681 OHM 1% 1/4W 144567
R5 RES MF 681 OHM 1% 1/4W 144567
R6 RES MF 110 OHM 1% 1/4W 144664
R7 RES SMD0805 1K 1/8W 1% 145007
R8 RES SMD0805 1K 1/8W 1% 145007
R9 RES SMD0805 1K 1/8W 1% 145007
R10 RES SMD0805 1K 1/8W 1% 145007
R11 RES MF 51.1 OHM 2% 1/4W 144720
R12 RES MF 249 OHM 1% 1/4W 144721
R13 RES MF 51.1 OHM 2% 1/4W 144720
R14 RES MF 249 OHM 1% 1/4W 144721
R15 RES SMD0805 1K 1/8W 1% 145007
R16 RES SMD0805 1K 1/8W 1% 145007
R17 RES SMD0805 1K 1/8W 1% 145007
R18 RES SMD0805 1K 1/8W 1% 145007
R19 RES MF 22.1 OHM 1% 1/4W 144554
R20 RES MF 22.1 OHM 1% 1/4W 144554
R21 RES MF 22.1 OHM 1% 1/4W 144554
R22 RES MF 22.1 OHM 1% 1/4W 144554
R23 RES MF 1.5K 1% 1/4W 144539
R24 RES MF 1.5K 1% 1/4W 144539
R25 RES MF 1.5K 1% 1/4W 144539
R26 RES MF 1.5K 1% 1/4W 144539
R29 RES MF 499 OHM 1% 1/4W 144510
R30 RES MF 499 OHM 1% 1/4W 144510
R31 RES MF 499 OHM 1% 1/4W 144510
R32 RES MF 499 OHM 1% 1/4W 144510
R33 RES MF 2.21K 1% 1/4W 144584
