C2500
87
PARTS LIST cont’d.
AUDIO PCB 751458 (Cont’d.)
Ref No. Description Part No.
4
Ref No. Description Part No.
BALANCED I/O PCB 751117
5
D1 DIODE ESD SUPPRESSOR SMD 070198
D2 DIODE ESD SUPPRESSOR SMD 070198
D3 DIODE ESD SUPPRESSOR SMD 070198
D4 DIODE ESD SUPPRESSOR SMD 070198
D5 DIODE ESD SUPPRESSOR SMD 070198
D6 DIODE ESD SUPPRESSOR SMD 070198
D7 DIODE ESD SUPPRESSOR SMD 070198
D8 DIODE ESD SUPPRESSOR SMD 070198
D9 DIODE ESD SUPPRESSOR SMD 070198
D10 DIODE ESD SUPPRESSOR SMD 070198
D11 DIODE ESD SUPPRESSOR SMD 070198
D12 DIODE ESD SUPPRESSOR SMD 070198
D13 DIODE ESD SUPPRESSOR SMD 070198
D14 DIODE ESD SUPPRESSOR SMD 070198
D15 DIODE ESD SUPPRESSOR SMD 070198
D16 DIODE ESD SUPPRESSOR SMD 070198
J1 CONN 18 PIN FFC SMD 118003
R193 RES SMD0805 47.5K 1/8W 1% 145013
R194 RES SMD0805 47.5K 1/8W 1% 145013
R195 RES SMD0805 47.5K 1/8W 1% 145013
R196 RES SMD0805 4.75K 1/8W 1% 145008
R197 RES SMD0805 22.1 1/8W 1% 145003
R198 RES SMD0805 22.1 1/8W 1% 145003
R199 RES SMD0805 4.75K 1/8W 1% 145008
R204 RES MF 4.99K 1% 1/4W 144521
R205 RES MF 4.99K 1% 1/4W 144521
R206 RES SMD0805 4.75K 1/8W 1% 145008
R207 RES SMD0805 4.75K 1/8W 1% 145008
R208 RES SMD0805 68.1K 1/8W 1% 145035
R209 RES SMD0805 150K 1/8W 1% 145037
R210 RES SMD0805 150K 1/8W 1% 145037
R211 RES SMD0805 2.21K 1/8W 1% 145024
R212 RES SMD0805 4.75K 1/8W 1% 145008
R213 RES SMD0805 4.75K 1/8W 1% 145008
R214 RES MF 1K 1% 1/4W 144513
R215 RES MF 1K 1% 1/4W 144513
R216 RES SMD0805 100K 1/8W 1% 145014
R217 RES SMD0805 100K 1/8W 1% 145014
R218 RES MF 221 OHM 1% 1/4W 144559
R219 RES MF 221 OHM 1% 1/4W 144559
R220 RES MF 267K 1% 1/4W 144532
R223 RES MF 267K 1% 1/4W 144532
R224 RES MF 1K 1% 1/4W 144513
R225 RES MF 1K 1% 1/4W 144513
R236 RES MF 22.1K 1% 1/4W 144564
R239 RES MF 22.1K 1% 1/4W 144564
R244 RES SMD0805 1K 1/8W 1% 145007
R245 RES SMD0805 1K 1/8W 1% 145007
R246 RES SMD0805 10K 1/8W 1% 145010
R258 RES MF 2.21K 1% 1/4W 144584
R259 RES SMD0805 1K 1/8W 1% 145007
R268 RES MF 1.65K 1% 1/4W 144516
R269 RES SMD0805 1K 1/8W 1% 145007
R274 RES MF 1.65K 1% 1/4W 144516
R275 RES MF 2.21K 1% 1/4W 144584
R280 RES SMD0805 221K 1/8W 1% 145038
R281 RES SMD0805 221K 1/8W 1% 145038
R286 RES MF 33.2K 1% 1/4W 144694
R287 RES MF 33.2K 1% 1/4W 144694
R288 RES MF 22.1K 1% 1/4W 144564
R289 RES MF 22.1K 1% 1/4W 144564
R290 RES FP 10 OHM 5% 1/4W 137105
R291 RES FP 10 OHM 5% 1/4W 137105
R292 RES MF 22.1K 1% 1/4W 144564
R293 RES MF 22.1K 1% 1/4W 144564
R294 RES MF 22.1K 1% 1/4W 144564
R295 RES MF 22.1K 1% 1/4W 144564
R297 RES MF 2.21K 1% 1/4W 144584
R299 RES MF 2.21K 1% 1/4W 144584
R300 RES MF 221 OHM 1% 1/4W 144559
R301 RES MF 221 OHM 1% 1/4W 144559
R302 RES MF 221 OHM 1% 1/4W 144559
R303 RES MF 221 OHM 1% 1/4W 144559
R304 RES MF 4.75K 1% 1/4W 144520
R305 RES MF 4.75K 1% 1/4W 144520
R306 RES MF 4.75K 1% 1/4W 144520
R307 RES SMD0805 10K 1/8W 1% 145010
R404 RES SMD0805 0 1/8W 0% 145016
R405 RES SMD0805 221K 1/8W 1% 145038
R406 RES SMD0805 221K 1/8W 1% 145038
R407 RES SMD0805 221K 1/8W 1% 145038
R408 RES SMD0805 221K 1/8W 1% 145038
R409 RES SMD0805 10K 1/8W 1% 145010
R410 RES SMD0805 100K 1/8W 1% 145014
R411 RES SMD0805 1.21K 1/8W 1% 145021
R412 RES SMD0805 1.21K 1/8W 1% 145021
R413 RES SMD0805 4.75K 1/8W 1% 145008
R414 RES SMD0805 4.75K 1/8W 1% 145008
R415 RES SMD0805 332 1/8W 1% 145006
R416 RES SMD0805 332 1/8W 1% 145006
U1 IC OP AMP LOW NOISE 5534 SMD 133719
U2 IC OP AMP LOW NOISE 5534 SMD 133719
U3 IC REGULATOR +5V 133569
U4 IC VOLTAGE REGULATOR -5.2V 133567
U7 IC REG POS ADJ 1.5A SMD 133822
U9 IC DUAL OP AMP 5532 SMD 133718
U10 IC DUAL OP AMP 5532 SMD 133718
U11 IC DUAL OP AMP 5532 SMD 133718
U12 IC DUAL OP AMP 5532 SMD 133718
U13 IC 8 BIT DRIVER SMD 133461
U14 IC 8 BIT DRIVER SMD 133461
U15 IC 8 BIT DRIVER SMD 133461
U16 IC 8 BIT DRIVER SMD 133461
U17 IC OP AMP LOW NOISE 5534 SMD 133719
U18 IC DUAL JFET OP AMP SMD 133778
U19 IC OP AMP LOW NOISE 5534 SMD 133719
U23 IC 2 CHANNEL VOLUME CNTRL SMD 133779
U24 IC TONE CONTROL 3-BAND SMD 133668
U26 IC OP AMP LOW NOISE 5534 SMD 133719
U27 IC OP AMP LOW NOISE 5534 SMD 133719
U28 IC DUAL OP AMP 5532 SMD 133718
U29 IC REG NEG ADJ 1.5A SMD 133821
U30 IC OP AMP 33178 SMD 133720
U31 IC SINGLE NAND SCHMITT SMD 133724
CABLE ASSY PHONO 173080
ASSY SMD AUDIO 701174
