C2500
91
PARTS LIST cont’d.
TUBE PCB 751461 (Cont’d.)
Ref No. Description Part No.
9
C3 CAP ELECT 47UF 35V 066446
C4 CAP ELECT 47UF 35V 066446
C7 CAP ELECT 10UF 250V 066558
C8 CAP PF 0.001UF 5% 400VDC 064453
C9 CAP PF 0.001UF 5% 400VDC 064453
C10 CAP MPF 0.0033UF 5% 63VDC 064455
C11 CAP MPF 0.0033UF 5% 63VDC 064455
C12 CAP ELECT 100UF 25V 066573
C13 CAP ELECT 100UF 25V 066573
C14 CAP POLYPROP 1uF 250V 20% 064433
C15 CAP POLYPROP 1uF 250V 20% 064433
C19 CAP MONO 47PF 200V 10% NPO 061340
C20 CAP MONO 47PF 200V 10% NPO 061340
C21 CAP ELECT 100UF 25V 066573
C22 CAP ELECT 100UF 25V 066573
C25 CAP PF 0.001UF 5% 400VDC 064453
C26 CAP PF 0.001UF 5% 400VDC 064453
C27 CAP MPF 0.0033UF 5% 63VDC 064455
C28 CAP MPF 0.0033UF 5% 63VDC 064455
C31 CAP POLYPROP 1uF 250V 20% 064433
C32 CAP POLYPROP 1uF 250V 20% 064433
C37 CAP ELECT 10UF 250V 066558
C40 CAP MPF 0.022UF 5% 63VDC 064316
C41 CAP MPF 0.022UF 5% 63VDC 064316
C42 CAP MONO 47PF 200V 10% NPO 061340
C43 CAP MONO 47PF 200V 10% NPO 061340
C44 CAP MONO 47PF 200V 10% NPO 061340
C45 CAP MONO 47PF 200V 10% NPO 061340
C47 CAP ELECT 10UF 250V 066558
C48 CAP ELECT 10UF 250V 066558
C49 CAP MPF 0.47UF 5% 100VDC 064442
C51 CAP MPF 0.47UF 5% 100VDC 064442
C55 CAP MONO 10PF 200V 10% NPO 061338
C56 CAP MONO 10PF 200V 10% NPO 061338
C57 CAP MONO 10PF 200V 10% NPO 061338
C58 CAP MONO 10PF 200V 10% NPO 061338
C59 CAP ELECT 100UF 25V 066573
C60 CAP ELECT 100UF 25V 066573
C61 CAP MONO .1UF 50V 20% Z5U 061346
C62 CAP MPF 0.022UF 5% 63VDC 064316
C63 CAP MPF 0.022UF 5% 63VDC 064316
DS1 LED GREEN 3MM HI-INTENSITY 058197
DS2 LED GREEN 3MM HI-INTENSITY 058197
DS3 LED GREEN 3MM HI-INTENSITY 058197
DS4 LED GREEN 3MM HI-INTENSITY 058197
DS5 LED GREEN 3MM HI-INTENSITY 058197
DS6 LED GREEN 3MM HI-INTENSITY 058197
J1 HEADER 2 PIN LATCHING 117766
J2 HEADER 2 PIN LATCHING 117766
J4 CONN 12 PIN FFC 117907
J5 8 PIN 2.5MM SHROUDED 118046
J6 CONN 12 PIN FFC 117907
J7 CONNECTOR 3PIN HEADER 2MM 118013
PCB1 PC BD TUBE 130181
Q1 TRANSISTOR PNP 300V BF421 132352
Q2 TRANSISTOR PNP 300V BF421 132352
Q3 TRANSISTOR PNP 300V BF421 132352
Q4 TRANSISTOR PNP 300V BF421 132352
Q5 TRANSISTOR PNP 300V BF421 132352
Q6 TRANSISTOR PNP 300V BF421 132352
Q8 TRANSISTOR NPN SILICON 132317
R1 RES MF 953 OHM 1% 1/4W 144661
R2 RES MF 6.49K .5% 1/4W 144617
R3 RES MF 953 OHM 1% 1/4W 144661
R4 RES MF 6.49K .5% 1/4W 144617
R5 RES MF 475K 1% 1/4W 144604
R6 RES MF 475K 1% 1/4W 144604
R7 RES MF 75K 1% 1/4W 144552
R8 RES MF 75K 1% 1/4W 144552
R9 RES MF 2.21M 1/4W 144576
R10 RES MF 2.21M 1/4W 144576
R11 RES MF 47.5K 1% 1/4W 144526
R12 RES MF 4.75K 1% 1/4W 144520
R13 RES MF 4.75K 1% 1/4W 144520
R14 RES MF 267K 1% 1/4W 144532
R15 RES MF 1M 1/4W 144577
R16 RES MF 267K 1% 1/4W 144532
R17 RES MF 1M 1/4W 144577
R18 RES MF 2.21K 1% 1/4W 144584
R19 RES MF 2.21K 1% 1/4W 144584
R20 RES MF 33.2K 1% 1/4W 144694
R21 RES MF 10K 1% 1/4W 144504
R22 RES MF 33.2K 1% 1/4W 144694
R26 RES MF 47.5K 1% 1/4W 144526
R29 RES MF 1.82K 1% 1/4W 144582
R30 RES MF 6.49K .5% 1/4W 144617
R31 RES MF 1.82K 1% 1/4W 144582
R32 RES MF 6.49K .5% 1/4W 144617
R33 RES MF 475K 1% 1/4W 144604
R34 RES MF 475K 1% 1/4W 144604
R35 RES MF 75K 1% 1/4W 144552
R36 RES MF 75K 1% 1/4W 144552
R37 RES MF 2.21M 1/4W 144576
R38 RES MF 2.21M 1/4W 144576
R39 RES MF 4.75K 1% 1/4W 144520
R40 RES MF 4.75K 1% 1/4W 144520
R41 RES MF 267K 1% 1/4W 144532
R44 RES MF 1M 1/4W 144577
R43 RES MF 267K 1% 1/4W 144532
R44 RES MF 1M 1/4W 144577
R47 RES MF 33.2K 1% 1/4W 144694
R48 RES MF 10K 1% 1/4W 144504
R49 RES MF 33.2K 1% 1/4W 144694
R50 RES MF 10K 1% 1/4W 144504
R56 RES MF 10K 1% 1/4W 144504
R57 RES MF 475K 1% 1/4W 144604
R58 RES MF 10K 1% 1/4W 144504
R55 RES MF 47.5K 1% 1/4W 144526
R59 RES MF 475K 1% 1/4W 144604
R60 RES MF 475K 1% 1/4W 144604
R61 RES MF 475K 1% 1/4W 144604
R62 RES MF 10K 1% 1/4W 144504
R63 RES MF 10K 1% 1/4W 144504
R64 RES MF 15K 1% 1/4W 144623
R65 RES MF 267K 1% 1/4W 144532
R66 RES MF 15K 1% 1/4W 144623
R67 RES MF 267K 1% 1/4W 144532
R69 RES MF 47.5K 1% 1/4W 144526
Ref No. Description Part No.
