PERFORMANCE LIMITS
Performance limits are the maximum deviation
from perfection permitted for a McIntosh instrument.
We promise you that when you purchase a new C 33
from
a
McIntosh franchised dealer,
it
will
be
capable
of
or can be made capable of performance at or exceed-
ing these limits or you can return the unit and get your
money back. McIntosh is the only manufacturer that
makes this statement.
FREQUENCY RESPONSE
+ 0, -
0.5dB
from
20Hz
to
20,000
Hz
MAXIMUM VOLTAGE OUTPUT
10 volts from 20Hz to 20,000Hz
TOTAL HARMONIC DISTORTION
0.01% maximum from 20Hz to 20,000Hz at rated
output
SENSITIVITY
Phono- 2mV for 2.5V rated output
(0.4mV IMF)
High Level- 250mV for 2.5V rated output
(50mV
IMF)
SIGNAL TO NOISE RATIO, A-WEIGHTED
Phono- 90dB below l0mV input
(84dB
IMF)
High Level- l00dB below rated output
(86dB
IHF)
MAXIMUM INPUT SIGNAL
Phono- l00mV
High Level- 10 volts
INPUT IMPEDANCE
Phono- 47k ohms and 65pF capacitance
High Level- 50k ohms
EQUALIZATION CONTROLS
Variable 12dB boost to 12dB cut at center
frequencies of 30, 15O, 500, 1500, 10k Hz
COMPANDOR RATIOS
From 1:2 compression to 2:1 expansion
LF FILTER
Flat
or
roll-off
at
12dB
per
octave
below
50 Hz.
HF FILTER
Flat
or
roll-off
at
12dB
per
octave
above
7,000
Hz.
CONTINUOUS AVERAGE POWER OUTPUT
20 watts per channel into 8 ohms, from 20Hz to
20kHz, at 0.01% maximum harmonic distortion
FREQUENCY RESPONSE
+ 0 -O.2dB from 20Hz to 20,000Hz
SENSITIVITY
750mV for rated output (170mV IHF),
input impedance is 27k ohms
SIGNAL TO NOISE RATIO, A-WEIGHTED
l00dB below rated output(87dB IHF}
SEMICONDUCTOR COMPLEMENT
31 Bipolar Transistors
76 Field Effect Transistors
35 Integrated Circuits
107 Diodes
1 Silicon Controlled Rectifier (SCR)
AC POWER OUTLETS
2 current-sensing, 100 watts, green
4 switched, 1200 watts total, black
POWER REQUIREMENTS
120 volts, 50/60 Hz, 25 to 85 watts
MECHANICAL INFORMATION
SIZE:
16 inches wide (40.6 cm) by 5-7/16 inches high
(13.8 cm) by 13 inches deep (33.0 cm), including
PANLOC shelf and back panel connectors. Knob
clearance required is 1-1/2 inches (3.81 cm) in front
of the mounting panel.
FINISH:
Front panel is anodized gold and black on white
flint
glass
with
special
gold/teal
nomenclature
illumination. Chassis is black.
MOUNTING:
Exclusive McIntosh developed professional PANLOC
WEIGHT:
26 pounds (11.8 kg) net, 38 pounds (17.2 kg) in
shipping carton.
Franchised Dealer:
O3945O
Printed
in
U.S.A.
MCINTOSH LABORATORY INC.
2
CHAMBERS
ST.,
BINGHAMTON, N.Y.
13903-2699
607-723-3512
MONITOR AMPLIFIER SECTION
PREAMPLIFIER SECTION
