McIntosh C8AC Service Manual

MC275
PARTS LIST
25
Ref. No. Description Part No.
1
INTERCONNECT
Ref. No. Description Part No.
BP1 MCINTOSH BINDING POST 084226
BP2 MCINTOSH BINDING POST 084226
BP3 MCINTOSH BINDING POST 084226
BP4 MCINTOSH BINDING POST 084226
BP5 MCINTOSH BINDING POST 084226
BP6 MCINTOSH BINDING POST 084226
BP7 MCINTOSH BINDING POST 084226
BP8 MCINTOSH BINDING POST 084226
CA1 CABLE ASSY AC 173124
CA2 CABLE ASSY AC 173124
CA3 CABLE ASSY AC 173124
CA4 CABLE ASSY RECEPTIACLE/GND WIRE 171723
CA5 CABLE ASSY 18 COND 90MM 171446
CA6 CABLE ASSY 12 COND 70MM 171318
CA7 CABLE ASSY 12 COND 70MM 171318
CA8 CABLE ASSY INPUT 173142
DS1 LED RED PANEL MOUNT ASSY 058194
F1 FUSEHOLDER 1/4” FASTONS 5X20 178190
J1 RECEPTACLE AC LINE 18GA QK-CNT 118006
JMP1 JUMPER BACK-UP 173085
L1 INDUCTOR FILTER 0.2H 122423
SW1 SWITCH ASSY ROCKER 052141
SW2 SWITCH ASSY ROCKER 052141
SW3 SWITCH ASSY ROCKER 052141
SW4 SWITCH ASSY ROCKER 052141
T1
TRANSFORMER POTTED POWER-CONTACT SERVICE
T2 TRANSFORMER POTTED OUTPUT 751327
T3 TRANSFORMER POTTED OUTPUT 751327
V1 TUBE 12AT7 SCREENED 165078
V2 TUBE 12AT7 SCREENED 165078
V3 TUBE 12AX7A SCREENED 165080
V4 TUBE 12AX7A SCREENED 165080
V5 TUBE 12AX7A SCREENED 165080
V6 TUBE 12AT7 SCREENED 165078
V7 TUBE 12AT7 SCREENED 165078
V8 TUBE KT88 SCREENED 165073
V9 TUBE KT88 SCREENED 165073
V10 TUBE KT88 SCREENED 165073
V11 TUBE KT88 SCREENED 165073
MAIN PCB 751376
2
C1 CAP POLY .047UF 10% 1000VDC 064434
C2 CAP ELECT 47UF 450V 066560
C3 CAP ELECT 1000UF 25V 066513
C4 CAP MONO .1UF 50V +_20% X7R SMD 061365
C5 CAP ELECT 680UF 315V 066618
C6 CAP ELECT 680UF 315V 066618
C7 CAP ELECT 22UF 450V 066597
C8 CAP ELECT 22UF 450V 066597
C9 CAP MONO .1UF 50V +_20% X7R SMD 061365
C10 CAP ELECT 3300UF 35V 066509
C11 CAP ELECT 22UF 450V 066597
C12 CAP ELECT 3300UF 35V 066509
C13 CAP ELECT 220UF 25V 066507
C14 CAP ELECT 22UF 450V 066597
C15 CAP ELECT 680UF 315V 066618
C16 CAP POLYPROP 0.22UF 400V 20% 064438
C17 CAP ELECT 680UF 315V 066618
C18 CAP ELECT 47UF 450V 066560
C19 CAP .47UF 50V 20% SMD0805 061373
C20 CAP .47UF 50V 20% SMD0805 061373
C21 CAP .47UF 50V 20% SMD0805 061373
C22 CAP MONO .1UF 50V +_20% X7R SMD 061365
C23 CAP MONO .1UF 50V +_20% X7R SMD 061365
C24 CAP MONO .1UF 50V +_20% X7R SMD 061365
C25 CAP MPF 0.47UF 5% 100VDC 064442
C26 CAP .01UF 50V 20% SMD0805 061372
C27 CAP ELECT 10UF 100VDC 066462
C28 CAP MONO .1UF 50V +_20% X7R SMD 061365
C29 CAP MONO .1UF 50V +_20% X7R SMD 061365
C30 CAP MONO .1UF 50V +_20% X7R SMD 061365
C31 CAP MONO .1UF 50V +_20% X7R SMD 061365
C32 CAP SMD0603 .22uF 10% 10V X7R 061387
C33 CAP MONO .1UF 50V +_20% X7R SMD 061365
C34 CAP .47UF 50V 20% SMD0805 061373
C35 CAP ELECT 220UF 25V 066507
C36 CAP ELECT 10UF 100VDC 066462
C37 CAP MONO .1UF 50V +_20% X7R SMD 061365
C38 CAP MONO .1UF 50V +_20% X7R SMD 061365
C39 CAP MONO .1UF 50V +_20% X7R SMD 061365
C40 CAP MONO .1UF 50V +_20% X7R SMD 061365
C41 CAP MONO .1UF 50V +_20% X7R SMD 061365
C42 CAP MONO .1UF 50V +_20% X7R SMD 061365
C43 CAP POLYPROP 1uF 250V 20% 064433
C44 CAP POLYPROP 1uF 250V 20% 064433
C45 CAP POLYPROP 1uF 250V 20% 064433
C46 CAP POLYPROP 1uF 250V 20% 064433
C47 CAPACITOR 2200PF 250VAC 10% 061375
C48 CAPACITOR 2200PF 250VAC 10% 061375
C49 CAP POLYPROP 0.22UF 20% 1KVDC 064432
C50 CAP POLYPROP 0.22UF 20% 1KVDC 064432
C51 CAP POLYPROP 0.22UF 20% 1KVDC 064432
C52 CAP POLYPROP 0.22UF 20% 1KVDC 064432
C53 CAP .47UF 50V 20% SMD0805 061373
C54 CAP ELECT 47UF 25V 20% BP 066556
C55 CAP ELECT 47UF 25V 20% BP 066556
C58 CAP ELECT 4.7UF 50V 066512
D1 DIODE SMALL SIGNAL 4148 SMD 070199
D2 DIODE SCHOTTKY 40V 2A SMD 070210
D3 DIODE SCHOTTKY 40V 2A SMD 070210
D4 DIODE SCHOTTKY 40V 2A SMD 070210
D5 DIODE SCHOTTKY 40V 2A SMD 070210
D6 DIODE SCHOTTKY 40V 2A SMD 070210
D7 DIODE BRID RECT 1000V 6A 070180
D8 DIODE RECTIFIER 1N4007 070178
D9 DIODE RECTIFIER 400V 1A SMD 070208
D10 DIODE RECTIFIER 400V 1A SMD 070208
D11 DIODE RECTIFIER 400V 1A SMD 070208
D12 DIODE RECTIFIER 400V 1A SMD 070208
D13 DIODE SCHOTTKY 40V 2A SMD 070210
D14 DIODE RECTIFIER 1N4007 070178
D15 DIODE RECTIFIER 1N4007 070178
D16 DIODE RECTIFIER 070175
D17 DIODE RECTIFIER 1N4007 070178
D18 DIODE RECTIFIER 070175
D19 DIODE SMALL SIGNAL 4148 SMD 070199
