26
Ref. No. Description Part No.
MAIN PCB 751376 (Cont’d.)
Ref. No. Description Part No.
PARTS LIST (Cont’d.)
2
D20 DIODE SMALL SIGNAL 4148 SMD 070199
D21 DIODE SMALL SIGNAL 4148 SMD 070199
D22 DIODE SMALL SIGNAL 4148 SMD 070199
D23 DIODE SMALL SIGNAL 4148 SMD 070199
D24 DIODE SMALL SIGNAL 4148 SMD 070199
DS1 LED RGB SMD 058199
J1 10 PIN SHROUDED HEADER 2MM 117973
J2 10 PIN SHROUDED HEADER 2MM 117973
J3 BLADE FASTON W/FEET 117708
J4 BLADE FASTON W/FEET 117708
J5 CONN 2 PIN MALE 117213
J6 BLADE FASTON W/FEET 117708
J7 BLADE FASTON W/FEET 117708
J8 BLADE FASTON W/FEET 117708
J9 BLADE FASTON W/FEET 117708
J10 BLADE FASTON W/FEET 117708
J11 BLADE FASTON W/FEET 117708
J12 BLADE FASTON W/FEET 117708
J13 BLADE FASTON W/FEET 117708
J14 BLADE FASTON W/FEET 117708
J15 BLADE FASTON W/FEET 117708
J16 BLADE FASTON .187 117726
J17 BLADE FASTON .187 117726
J18 BLADE FASTON W/FEET 117708
J19 BLADE FASTON W/FEET 117708
J20 BLADE FASTON W/FEET 117708
J21 BLADE FASTON W/FEET 117708
J22 BLADE FASTON W/FEET 117708
J24 BLADE FASTON W/FEET 117708
J25 BLADE FASTON W/FEET 117708
J26 HEADER 2 PIN LATCHING 117766
J27 HEADER 2 PIN LATCHING 117766
J28 HEADER 2 PIN LATCHING 117766
J29 CONN 18 PIN FFC SMD 118003
J30 CONN 12 PIN FFC SMD 118001
J31 CONN 12 PIN FFC SMD 118001
J32 CONN HEADER 14 PIN 0.2” 118008
J33 CONN HEADER 14 PIN 0.2” 118008
J34 CONN 2 PIN MALE 117213
J35 BLADE FASTON .187 117726
J36 BLADE FASTON .187 117726
J37 BLADE FASTON .187 117726
J38 BLADE FASTON .187 117726
J39 BLADE FASTON .187 117726
J40 BLADE FASTON .187 117726
J41 BLADE FASTON .187 117726
J42 BLADE FASTON .187 117726
J43 BLADE FASTON .187 117726
J44 BLADE FASTON .187 117726
J45 BLADE FASTON .187 117726
J46 BLADE FASTON .187 117726
J47 BLADE FASTON .187 117726
J48 BLADE FASTON .187 117726
K1 RELAY POWER TV8 12V 087087
L1 CHOKE 2.2 uH 122405
L2 CHOKE 2.2 uH 122405
L3 CHOKE 2.2 uH 122405
L4 CHOKE 2.2 uH 122405
MP1 STANDOFF PCB 5/16” NYLON 412160
PCB1 PC BD MAIN 130138
Q1 TRANSISTOR NPN NPN A05 SMD 132333
Q2 TRANSISTOR PNP A55 SMD 132334
Q3 TRANSISTOR NPN NPN A05 SMD 132333
Q4 TRANSISTOR NPN NPN A05 SMD 132333
Q5 TRANSISTOR NPN NPN A05 SMD 132333
Q6 TRANSISTOR NPN NPN A05 SMD 132333
Q7 TRANSISTOR NPN NPN A05 SMD 132333
Q8 TRANS NPN W/R1R2 10K/10K SMD 132346
Q9 TRANSISTOR PCH MMBFJ176 SMD 132355
Q10 TRANS NPN W/R1R2 10K/10K SMD 132346
Q11 TRANS NPN W/R1R2 10K/10K SMD 132346
Q12 TRANS NPN W/R1R2 10K/10K SMD 132346
Q13 TRANS NPN W/R1R2 10K/10K SMD 132346
Q14 TRANS NPN W/R1R2 10K/10K SMD 132346
Q15 TRANS NPN W/R1R2 10K/10K SMD 132346
Q16 TRANSISTOR NPN NPN A05 SMD 132333
Q17 TRANSISTOR NPN NPN A05 SMD 132333
Q18 TRANSISTOR NPN NPN A05 SMD 132333
Q19 TRANSISTOR NPN NPN A05 SMD 132333
R1 FUSE 0.35A 16V RESET 1206 SMD 145054
R2 POLYSWITCH 8A 30V 144750
R3 POLYSWITCH 3.00A 72V 144722
R4 RES MO 430 OHM .5W 5% 137101
R5 RES FUSING 1OHM 2W 5% 139277
R6 RES FUSING 1OHM 2W 5% 139277
R7 RES MO 430 OHM .5W 5% 137101
R8 RES MO 2.2K 5% 2W 144666
R9 RES SMD0805 4.75K 1/8W 1% 145008
R10 RES MO 100K 2W 5% 144698
R11 RES MO 100K 2W 5% 144698
R12 RES MF 267K 1% 1/4W 144532
R13 RES MF 47.5K 1% 1/4W 144526
R14 RES MF 100K 1% 1/4W 144528
R15 RES MF 681 OHM 1% 1/4W 144567
R16 RES SMD0805 10K 1/8W 1% 145010
R17 RES SMD0805 4.75K 1/8W 1% 145008
R18 RES SMD0805 10K 1/8W 1% 145010
R19 POT TRIM 100K OHM 20% 134504
R20 RES SMD0805 2.21K 1/8W 1% 145024
R21 RES MO 46.4K 1% 1W 144637
R22 RES MO 30K 5% 2W 144602
R23 RES SMD0805 4.75K 1/8W 1% 145008
R24 RES SMD0805 4.75K 1/8W 1% 145008
R25 RES SMD0805 4.75K 1/8W 1% 145008
R26 RES SMD0805 4.75K 1/8W 1% 145008
R27 RES SMD0805 10K 1/8W 1% 145010
R28 RES SMD0805 10K 1/8W 1% 145010
R29 RES SMD0805 2.21K 1/8W 1% 145024
R30 RES SMD0805 47.5K 1/8W 1% 145013
R31 RES SMD0805 2.21K 1/8W 1% 145024
R32 RES SMD0805 47.5 1/8W 1% 145004
R33 RES SMD0805 47.5 1/8W 1% 145004
R34 RES SMD0805 4.75K 1/8W 1% 145008
R35 RES SMD0805 2.21M 1/8W 1% 145043
R36 RES SMD0805 2.21M 1/8W 1% 145043
R37 RES SMD0805 221K 1/8W 1% 145038
R38 RES SMD0805 2.21M 1/8W 1% 145043
R39 RES SMD0805 10K 1/8W 1% 145010
