MC275
Ref. No. Description Part No.
MAIN PCB 751376 (Cont’d.)
Ref. No. Description Part No.
PARTS LIST (Cont’d.)
27
2
R40 RES SMD0805 2.21K 1/8W 1% 145024
R41 RES SMD0805 100K 1/8W 1% 145014
R42 RES SMD0805 100K 1/8W 1% 145014
R43 RES SMD0805 221K 1/8W 1% 145038
R44 RES SMD0805 22.1K 1/8W 1% 145012
R45 RES SMD0805 2.21M 1/8W 1% 145043
R46 RES SMD0805 100K 1/8W 1% 145014
R47 RES SMD0805 2.21M 1/8W 1% 145043
R48 RES SMD0805 22.1K 1/8W 1% 145012
R49 RES SMD0805 22.1K 1/8W 1% 145012
R50 RES SMD0805 68.1K 1/8W 1% 145035
R51 RES SMD0805 4.75K 1/8W 1% 145008
R52 RES SMD0805 47.5K 1/8W 1% 145013
R53 RES SMD0805 2.21M 1/8W 1% 145043
R54 RES SMD0805 2.21M 1/8W 1% 145043
R55 RES SMD0805 332K 1/8W 1% 145039
R56 RES SMD0805 47.5K 1/8W 1% 145013
R57 RES SMD0805 22.1K 1/8W 1% 145012
R58 RES SMD0805 47.5 1/8W 1% 145004
R59 RES SMD0805 47.5 1/8W 1% 145004
R60 RES MO 30K 5% 2W 144602
R61 RES MO 30K 5% 2W 144602
R62 RES MO 30K 5% 2W 144602
R63 RES MO 30K 5% 2W 144602
R64 RES MO 100K 2W 5% 144698
R65 RES MO 100K 2W 5% 144698
R66 RES MO 100K 2W 5% 144698
R67 RES MO 100K 2W 5% 144698
R68 RES WW 220 OHM 5% 5W 139275
R69 RES WW 220 OHM 5% 5W 139275
R70 RES WW 220 OHM 5% 5W 139275
R71 RES WW 220 OHM 5% 5W 139275
R72 RES MF 221K 1% 1/4W 144629
R73 RES MF 221K 1% 1/4W 144629
R74 RES SMD0805 100K 1/8W 1% 145014
R75 RES MF 475K 1% 1/4W 144604
R76 RES MF 475K 1% 1/4W 144604
R77 RES SMD0805 100K 1/8W 1% 145014
R78 RES WW 2 OHM 10% 5W W/FEET 139253
R79 RES WW 2 OHM 10% 5W W/FEET 139253
R80 RES MF 22.1K 1% 1/4W 144564
R81 RES MF 22.1K 1% 1/4W 144564
R84 RES SMD0805 4.75K 1/8W 1% 145008
RT1 THERMISTOR 16 OHM 144282
RT2 THERMISTOR 16 OHM 144282
T1 TRANSFORMER BACKUP 159376
U1 IC REGULATOR 5V 500mA SMD 133737
U2 IC OPTOCOUPLER,PHOTOTRANSISTOR 131031
U3 IC SINGLE NAND SCHMITT SMD 133724
U4 IC SINGLE NAND SCHMITT SMD 133724
U5 IC SINGLE NAND SCHMITT SMD 133724
U6 IC SINGLE NAND SCHMITT SMD 133724
U7 IC SINGLE NAND SCHMITT SMD 133724
U8 IC LATCH R-S QUAD NOR SMD 133795
U9 IC SINGLE 2 INPUT OR GATE SMD 133700
U10 IC TIMER/OSC LM555 SMD 133793
U11 IC SINGLE 2 INPUT OR GATE SMD 133700
U12 IC SINGLE NAND SCHMITT SMD 133724
U13 IC SINGLE 2 INPUT OR GATE SMD 133700
U14 IC SINGLE 2-INPUT NOR GATE SMD 133500
U15 IC SINGLE 2 INPUT OR GATE SMD 133700
U16 IC DECADE COUNTER SMD 133794
U17 IC SINGLE NAND SCHMITT SMD 133724
U18 IC PROGRAMMABLE TIMER SMD 133813
U19 IC SINGLE NAND SCHMITT SMD 133724
U20 IC SINGLE 2 INPUT OR GATE SMD 133700
U21 IC SINGLE NAND SCHMITT SMD 133724
U22 IC SINGLE NAND SCHMITT SMD 133724
U23 IC SINGLE 2 INPUT OR GATE SMD 133700
U24 IC LATCH R-S QUAD NOR SMD 133795
U25 IC LATCH R-S QUAD NOR SMD 133795
U26 IC SINGLE 2-INPUT NOR GATE SMD 133500
U27 IC SINGLE NAND SCHMITT SMD 133724
U28 IC SINGLE 2-INPUT AND GATE SMD 133502
U29 IC SINGLE NAND SCHMITT SMD 133724
U30 IC SINGLE NAND SCHMITT SMD 133724
U31 IC SINGLE NAND SCHMITT SMD 133724
V8 SOCKET OCTAL TUBE CERAMIC 178196
V9 SOCKET OCTAL TUBE CERAMIC 178196
V10 SOCKET OCTAL TUBE CERAMIC 178196
V11 SOCKET OCTAL TUBE CERAMIC 178196
AMPLIFIER PCB 751377
3
C1 CAP ELECT 10UF 250V 066558
C2 CAP ELECT 100UF 25V 066573
C3 CAP ELECT 100UF 25V 066573
C4 CAP POLYPROP 1uF 250V 20% 064433
C5 CAP ELECT 220UF 25V 066507
C6 CAP POLYPROP 1uF 250V 20% 064433
C7 CAP 100PF 50V NPO SMD0805 061316
C8 CAP 100PF 50V NPO SMD0805 061316
C9 CAP MONO .1UF 50V +_20% SMD0805 061365
C14 CAP 100PF 50V NPO SMD0805 061316
C15 CAP 100PF 50V NPO SMD0805 061316
C16 CAP MPF 0.1UF 5% 63VDC 064325
C17 CAP MPF 0.1UF 5% 63VDC 064325
C18 CAP ELECT 100UF 25V 066573
C19 CAP ELECT 100UF 25V 066573
C20 CAP ELECT 100UF 25V 066573
C21 CAP ELECT 100UF 25V 066573
C22 CAP POLYPROP 0.047UF 10% 275VDC 064466
C23 CAP POLYPROP 0.047UF 10% 275VDC 064466
C24 CAP POLYPROP 0.047UF 10% 275VDC 064466
C25 CAP POLYPROP 0.047UF 10% 275VDC 064466
C26 CAP ELECT 1000UF 16V NP 066500
C27 CAP ELECT 1000UF 16V NP 066500
C28 CAP POLY .047UF 10% 1000VDC 064434
C29 CAP POLY .047UF 10% 1000VDC 064434
C30 CAP POLY .047UF 10% 1000VDC 064434
C31 CAP POLY .047UF 10% 1000VDC 064434
C32 CAP POLYPROP 1uF 250V 20% 064433
C33 CAP POLYPROP 1uF 250V 20% 064433
C34 CAP POLYPROP 1uF 250V 20% 064433
C35 CAP POLYPROP 1uF 250V 20% 064433
C36 CAP MPF 0.47UF 5% 100VDC 064442
C37 CAP MPF 0.47UF 5% 100VDC 064442
C38 CAP ELECT 4.7UF 50V 066512
C39 CAP ELECT 4.7UF 50V 066512
