McIntosh C8AC Service Manual

Ref. No. Description Part No.
AMP PCB 751377 (Cont’d.)
Ref. No. Description Part No.
PARTS LIST (Cont’d.)
28
3
C40 CAP ELECT 4.7UF 50V 066512
C41 CAP ELECT 4.7UF 50V 066512
D1 DIODE ZENER 200V 1.5W 070177
D2 DIODE SMALL SIGNAL 4148 SMD 070199
D3 DIODE SMALL SIGNAL 4148 SMD 070199
D4 DIODE ZENER 200V 1.5W 070177
D5 DIODE ZENER 200V 1.5W 070177
D6 DIODE ZENER 200V 1.5W 070177
D7 DIODE ZENER 200V 1.5W 070177
D8 DIODE ZENER 200V 1.5W 070177
D9 DIODE ZENER 200V 1.5W 070177
D10 DIODE ZENER 200V 1.5W 070177
D11 DIODE ZENER 200V 1.5W 070177
D12 DIODE SMALL SIGNAL 4148 SMD 070199
D13 DIODE SMALL SIGNAL 4148 SMD 070199
D14 DIODE SMALL SIGNAL 4148 SMD 070199
D15 DIODE SMALL SIGNAL 4148 SMD 070199
D16 DIODE SMALL SIGNAL 4148 SMD 070199
D17 DIODE SMALL SIGNAL 4148 SMD 070199
D18 DIODE SMALL SIGNAL 4148 SMD 070199
D19 DIODE SMALL SIGNAL 4148 SMD 070199
D20 DIODE SMALL SIGNAL 4148 SMD 070199
D21 DIODE SMALL SIGNAL 4148 SMD 070199
D22 DIODE SMALL SIGNAL 4148 SMD 070199
D23 DIODE SMALL SIGNAL 4148 SMD 070199
D24 DIODE SMALL SIGNAL 4148 SMD 070199
D25 DIODE SMALL SIGNAL 4148 SMD 070199
D26 DIODE SMALL SIGNAL 4148 SMD 070199
D27 DIODE SMALL SIGNAL 4148 SMD 070199
D28 DIODE SMALL SIGNAL 4148 SMD 070199
D29 DIODE SMALL SIGNAL 4148 SMD 070199
D30 DIODE SMALL SIGNAL 4148 SMD 070199
D31 DIODE SMALL SIGNAL 4148 SMD 070199
D32 DIODE SMALL SIGNAL 4148 SMD 070199
D33 DIODE SMALL SIGNAL 4148 SMD 070199
D34 DIODE SMALL SIGNAL 4148 SMD 070199
D35 DIODE SMALL SIGNAL 4148 SMD 070199
D36 DIODE SMALL SIGNAL 4148 SMD 070199
D37 DIODE SMALL SIGNAL 4148 SMD 070199
D38 DIODE SMALL SIGNAL 4148 SMD 070199
DS1 LED RGB SMD 058199
DS2 LED RGB SMD 058199
DS3 LED RGB SMD 058199
DS4 LED RGB SMD 058199
DS5 LED RGB SMD 058199
DS6 LED RGB SMD 058199
DS7 LED RGB SMD 058199
J1 7 PIN SHROUDED HEADER 117910
J2 HEADER 2 PIN LATCHING 117766
J3 HEADER 2 PIN LATCHING 117766
J4 CONN 12 PIN FFC SMD 118001
J5 CONN ELEVATED SOCKET 27 PIN 118009
J6 CONN ELEVATED SOCKET 27 PIN 118009
J7 CONN FFC 18PIN 117908
J8 JACK HEADPHONE DUAL BLACK 1/8” 117825
J9 JACK DUAL RCA 118020
J10 XLR FEMALE VERTICAL WITH LATCH 117813
J11 XLR FEMALE VERTICAL WITH LATCH 117813
J12 CONN 4-PIN RIGHT ANGLE 117927
J13 CONN 12 PIN FFC SMD 118001
J14 7 PIN SHROUDED HEADER 117910
K1 RELAY DPDT SIGNAL 12V SMD 087084
K2 RELAY DPDT SIGNAL 12V SMD 087084
MP1 STANDOFF PCB 5/16” NYLON 412160
MP2 STANDOFF PCB 5/16” NYLON 412160
MP3 STANDOFF PCB 5/16” NYLON 412160
MP4 STANDOFF PCB 5/16” NYLON 412160
MP5 STANDOFF PCB 5/16” NYLON 412160
MP6 RETAINER LITEPIPE LED 078045
MP7 LITEPIPE LED 0.8L X 0.1 DIA 163113
MP8 RETAINER LITEPIPE LED 078045
MP9 LITEPIPE LED 0.8L X 0.1 DIA 163113
MP10 RETAINER LITEPIPE LED 078045
MP11 LITEPIPE LED 0.8L X 0.1 DIA 163113
MP12 RETAINER LITEPIPE LED 078045
MP13 LITEPIPE LED 0.8L X 0.1 DIA 163113
MP14 RETAINER LITEPIPE LED 078045
MP15 LITEPIPE LED 0.8L X 0.1 DIA 163113
MP16 RETAINER LITEPIPE LED 078045
MP17 LITEPIPE LED 0.8L X 0.1 DIA 163113
MP18 RETAINER LITEPIPE LED 078045
MP19 LITEPIPE LED 0.8L X 0.1 DIA 163113
PCB1 PC BD AMPLIFIER 130142
Q1 TRANSISTOR PNP 300V BF421 132352
Q2 TRANSISTOR PNP 300V BF421 132352
Q3 TRANSISTOR NCH MMBFJ108 SMD 132354
Q4 TRANSISTOR NCH MMBFJ108 SMD 132354
R1 RES SMD0805 2.21K 1/8W 1% 145024
R3 RES MO 46.4K 1% 1W 144637
R4 RES MF 100K 1% 1/4W 144528
R5 RES MF 100K 1% 1/4W 144528
R6 RES MF 221K 1% 1/4W 144629
R7 RES SMD0805 3.32K 1/8W 1% 145026
R8 RES SMD0805 2.21K 1/8W 1% 145024
R9 RES MF 221K 1% 1/4W 144629
R10 RES MF 100K 1% 1/4W 144528
R11 RES MF 10K 1% 1/4W 144504
R12 RES MF 221K 1% 1/4W 144629
R13 RES SMD0805 3.32K 1/8W 1% 145026
R14 RES SMD0805 2.21K 1/8W 1% 145024
R15 RES FP 100 OHM 5% 1/4W 137107
R16 RES MF 221K 1% 1/4W 144629
R17 RES MF 100K 1% 1/4W 144528
R18 RES SMD0805 10K 1/8W 1% 145010
R19 RES SMD0805 10K 1/8W 1% 145010
R20 RES MF 22.1K 1% 1/4W 144564
R21 RES MF 22.1K 1% 1/4W 144564
R22 RES MF 10K 1% 1/4W 144504
R23 RES MF 22.1K 1% 1/4W 144564
R24 RES MF 22.1K 1% 1/4W 144564
R25 RES SMD0805 1K 1/8W 1% 145007
R26 RES SMD0805 1K 1/8W 1% 145007
R27 RES SMD0805 2.21M 1/8W 1% 145043
R28 RES SMD0805 2.21M 1/8W 1% 145043
R29 RES MF 10K 1% 1/4W 144504
R31 RES MF 10K 1% 1/4W 144504
R33 RES MF 100K 1% 1/4W 144528
R34 RES MF 100K 1% 1/4W 144528
