5
Adequate ventilation extends the trouble free life of
the MC275. Always allow air to flow through the
ventilation holes on the bottom of the amplifier and a
means for the warm air to escape at the top. Refer to
figure 9.
Allow at least 19 inches (48.3cm) above the top; 4
inches (10.2cm) for the Rear and Sides; allow 1/2 inch
(1.3cm) below the Power Amplifier so the airflow is
not obstucted.
Ventilation
Figure 3
Figure 7A
Figure 6
Figure 4
Figure 5
Figure 7B
Warm Air
Cool Air
Figure 9
Foam Insert
Unpacking the MC275 and Ventilation
Figure 8
Tube Cover
Screw
Tube Cover
Screw
To Next Page
