McIntosh MA6300

MA6300
37
PARTS LIST
MAIN PCB 050276
Ref No. Description Part No.
2
Ref No. Description Part No.
C1 CAP POLYPROP 0.15UF 10% 250VDC 064363
C2 CAP MPF 0.1UF 5% 63VDC 064325
C3 CAP MONO .1UF 50V 20% Z5U 061346
C4 CAP ELECT 3300UF 35V 066509
C5 CAP ELECT 22000UF 63V 066557
C6 CAP ELECT 3300UF 35V 066509
C7 CAP ELECT 22000UF 63V 066557
C8 CAP ELECT 3300UF 35V 066509
C9 CAP ELECT 3300UF 35V 066509
C10 CAP ELECT 3300UF 35V 066509
C11 CAP ELECT 1000UF 25V 066513
C12 CAP ELECT 1000UF 25V 066513
C13 CAP ELECT 220UF 25V 066507
C14 CAP MONO .1UF 50V 20% Z5U 061346
C15 CAP MONO .1UF 50V 20% Z5U 061346
C16 CAP MONO .1UF 50V 20% Z5U 061346
C17 CAP ELECT 47UF 35V 066446
C18 CAP MONO .1UF 50V 20% Z5U 061346
C19 CAP ELECT 10UF 50V 066445
C20 CAP ELECT 10UF 50V 066445
C21 CAP MONO 220PF 200V 10% NPO 061342
C22 CAP MONO .1UF 50V 20% Z5U 061346
C23 CAP MONO .1UF 50V 20% Z5U 061346
C24 CAP MONO .1UF 50V 20% Z5U 061346
C25 CAP MONO .1UF 50V 20% Z5U 061346
C28 CAP ELECT 10UF 16V 066580
C29 CAP ELECT 10UF 16V 066580
C30 CAP ELECT 10UF 16V 066580
C31 CAP ELECT 10UF 16V 066580
C32 CAP ELECT 10UF 16V 066580
C33 CAP ELECT 10UF 16V 066580
C34 CAP ELECT 10UF 16V 066580
C35 CAP ELECT 10UF 16V 066580
C36 CAP ELECT 10UF 16V 066580
C37 CAP ELECT 10UF 16V 066580
C38 CAP ELECT 10UF 16V 066580
C39 CAP ELECT 10UF 16V 066580
C40 CAP ELECT 10UF 16V 066580
C41 CAP ELECT 10UF 16V 066580
C42 CAP ELECT 10UF 16V 066580
C43 CAP ELECT 10UF 16V 066580
C44 CAP ELECT 10UF 16V 066580
C45 CAP ELECT 10UF 16V 066580
C46 CAP ELECT 10UF 16V 066580
C47 CAP MONO 100PF 100V 10% NPO 061341
C48 CAP MONO 47PF 200V 10% NPO 061340
C49 CAP ELECT 10UF 16V 066580
C50 CAP ELECT 10UF 16V 066580
C51 CAP ELECT 10UF 16V 066580
C52 CAP ELECT 10UF 16V 066580
C53 CAP MONO 100PF 100V 10% NPO 061341
C54 CAP MONO 100PF 100V 10% NPO 061341
C55 CAP MONO 100PF 100V 10% NPO 061341
C56 CAP MONO 100PF 100V 10% NPO 061341
C57 CAP ELECT 47UF 35V 066446
C58 CAP MONO 100PF 100V 10% NPO 061341
C59 CAP MONO 100PF 100V 10% NPO 061341
C60 CAP ELECT 10UF 16V 066580
C61 CAP ELECT 470UF 16V 066508
C62 CAP ELECT 470UF 16V 066508
C63 CAP MONO 100PF 100V 10% NPO 061341
C64 CAP MONO 47PF 200V 10% NPO 061340
C65 CAP MONO 100PF 100V 10% NPO 061341
C66 CAP MONO 47PF 200V 10% NPO 061340
C67 CAP MONO 100PF 100V 10% NPO 061341
C68 CAP MONO 47PF 200V 10% NPO 061340
C69 CAP MPF 0.01UF 5% 63VDC 064312
C70 CAP MPF 0.01UF 5% 63VDC 064312
C71 CAP MPF 0.033UF 5% 63VDC 064318
C72 CAP MPF 0.033UF 5% 63VDC 064318
C73 CAP ELECT 47UF 35V 066446
C74 CAP MONO .1UF 50V 20% Z5U 061346
C75 CAP MONO .1UF 50V 20% Z5U 061346
D1 DIODE RECTIFIER 070175
D2 DIODE SILICON 070174
D3 DIODE SILICON 070174
D4 DIODE SILICON 070174
D5 DIODE SIL 400 PIV @ 1.5A 070031
D6 DIODE SIL 400 PIV @ 1.5A 070031
D7 DIODE SIL 400 PIV @ 1.5A 070031
D8 DIODE SIL 400 PIV @ 1.5A 070031
D9 RECTIFIER BRIDGE PCB 35A 600V 070187
D10 DIODE SIL 400 PIV @ 1.5A 070031
D11 DIODE SIL 400 PIV @ 1.5A 070031
D12 DIODE SIL 400 PIV @ 1.5A 070031
D13 DIODE SIL 400 PIV @ 1.5A 070031
D14 DIODE SILICON 070174
D15 DIODE SILICON 070174
D16 DIODE SILICON 070174
GP4 BRACKET PCB CARD MOUNTING 003611
(GP4) RIVET 1/8X3/16 STEEL 108011
GP5 BRACKET PCB CARD MOUNTING 003611
(GP5) RIVET 1/8X3/16 STEEL 108011
HS1 HEATSINK T0220 080021
(HS1) SCREW MACH 4-40X1/4 PAN PH BLK 400121
(HS1) NUT KEP 4-40 CLR 402001
(HS1) INSULATOR ISOSTRATE TO 220 084133
HS2 HEATSINK T0220 080021
(HS2) SCREW MACH 4-40X1/4 PAN PH BLK 400121
(HS2) NUT KEP 4-40 CLR 402001
(HS2) INSULATOR ISOSTRATE TO 220 084133
HS3 HEATSINK T0220 080021
(HS3) SCREW MACH 4-40X1/4 PAN PH BLK 400121
(HS3) NUT KEP 4-40 CLR 402001
(HS3) INSULATOR ISOSTRATE TO 220 084133
J1 BLADE FASTON W/FEET 117708
J2 BLADE FASTON W/FEET 117708
J3 BLADE FASTON W/FEET 117708
J4 BLADE FASTON W/FEET 117708
J5 BLADE FASTON W/FEET 117708
J6 BLADE FASTON W/FEET 117708
J7 BLADE FASTON W/FEET 117708
J8 CONN 2 PIN MALE 117213
J9 CONN 3 POS MALE LARGE FRCTN LK 117293
J10 CONN 23 PIN FFC 117906
J11 JACK HEADPHONE DUAL BLACK 1/8” 117549
J12 JACK HEADPHONE DUAL BLACK 1/8” 117549
J13 JACK HEADPHONE DUAL BLACK 1/8” 117549
J14 JACK HEADPHONE DUAL BLACK 1/8” 117549
J15 CONN 12 PIN FFC 117907
