McIntosh MA6300

38
PARTS LIST cont’d.
MAIN PCB 050276 (Cont’d.)
Ref No. Description Part No.
Ref No. Description Part No.
J16 JACK RCA 4X2 WHT/RED 14MM 117791
J17 JACK RCA 4X2 WHT/RED 14MM 117791
J18 CONN XLR FEM HORIZ PCB LATCH 117814
J19 CONN XLR FEM HORIZ PCB LATCH 117814
J20 JACK RCA 1X2 WHT/RED 14MM 117788
K1 RELAY 12VDC 5A 250VAC TV-4 087077
K2 RELAY REED SPST-NO 5V 1.2A 087078
K3 RELAY REED SPST-NO 5V 1.2A 087078
K4 RELAY REED SPST-NO 5V 1.2A 087078
K5 RELAY REED SPST-NO 5V 1.2A 087078
K6 RELAY REED SPST-NO 5V 1.2A 087078
K7 RELAY REED SPST-NO 5V 1.2A 087078
K8 RELAY REED SPST-NO 5V 1.2A 087078
K9 RELAY REED SPST-NO 5V 1.2A 087078
K10 RELAY REED SPST-NO 5V 1.2A 087078
K11 RELAY REED SPST-NO 5V 1.2A 087078
K12 RELAY REED SPST-NO 5V 1.2A 087078
K13 RELAY REED SPST-NO 5V 1.2A 087078
K14 RELAY REED SPST-NO 5V 1.2A 087078
K15 RELAY REED SPST-NO 5V 1.2A 087078
K16 RELAY REED SPST-NO 5V 1.2A 087078
K17 RELAY REED SPST-NO 5V 1.2A 087078
K18 RELAY REED SPST-NO 5V 1.2A 087078
K19 RELAY REED SPST-NO 5V 1.2A 087078
PCB1 PC BD MAIN 129655
Q1 TRANSISTOR PNP SILICON 132304
Q2 TRANSISTOR NPN SILICON 132317
Q3 TRANSISTOR PNP SILICON 132304
Q4 TRANSISTOR NPN SILICON 132317
R1 RES POLYSWITCH RXE110 144671
R2 RES POLYSWITCH RXE110 144671
R3 RES MF 2.21 OHM 1% 1/4W 144607
R4 RES MF 22.1K OHM 1% 1/4W 144564
R5 RES MF 100K 1% 1/4W 144528
R6 RES MF 47.5K 1% 1/4W 144526
R7 RES MF 47.5K 1% 1/4W 144526
R8 RES MF 47.5K 1% 1/4W 144526
R9 RES NETWORK 9X-1-223 144498
R10 RES MF 10K 1% 1/4W 144504
R11 RES MF 10 OHM 1% 1/4W 144553
R12 RES MF 100 OHM 1% 1/4W 144568
R13 RES MF 475K 1% 1/4W 144604
R14 RES NETWORK 9X-1-223 144498
R15 RES MF 2.21 OHM 1% 1/4W 144607
R16 RES MF 1K 1% 1/4W 144513
R17 RES MF 100K 1% 1/4W 144528
R18 RES MF 3.32K 1% 1/4W 144518
R19 RES MF 182 OHM 1% 1/4W 144579
R20 RES MF 182 OHM 1% 1/4W 144579
R21 RES MF 182 OHM 1% 1/4W 144579
R22 RES MF 100 OHM 1% 1/4W 144568
R23 RES MF 100 OHM 1% 1/4W 144568
R24 RES MF 100 OHM 1% 1/4W 144568
R25 RES MF 100 OHM 1% 1/4W 144568
R26 RES MF 100 OHM 1% 1/4W 144568
R27 RES MF 100 OHM 1% 1/4W 144568
R28 RES MF 100 OHM 1% 1/4W 144568
R29 RES MET OX 47 OHM 5% 1/2W 137102
R30 RES MF 10K 1% 1/4W 144504
R31 RES MF 10K 1% 1/4W 144504
R33 RES MF 221 OHM 1% 1/4W 144559
R34 RES NETWORK 2X220K ISO 144678
R35 RES MF 221 OHM 1% 1/4W 144559
R36 RES NETWORK 2X220K ISO 144678
R37 RES NETWORK 2X220K ISO 144678
R38 RES NETWORK 2X220K ISO 144678
R39 RES NETWORK 2X220K ISO 144678
R40 RES NETWORK 2X220K ISO 144678
R41 RES NET 2 X 22K ISOLATED 144689
R42 RES NET 2 X 22K ISOLATED 144689
R43 RES MF 22.1K OHM 1% 1/4W 144564
R44 RES MF 1K 1% 1/4W 144513
R45 RES NETWORK 2X220K ISO 144678
R46 RES MF 1K 1% 1/4W 144513
R47 RES MF 1K 1% 1/4W 144513
R48 RES MF 20K 1% 1/4W 144524
R49 RES MF 20K 1% 1/4W 144524
R50 RES MF 20K 1% 1/4W 144524
R51 RES MF 20K 1% 1/4W 144524
R52 RES MF 10K 1% 1/4W 144504
R53 RES MF 10K 1% 1/4W 144504
R54 RES MF 10K 1% 1/4W 144504
R55 RES MF 10K 1% 1/4W 144504
R56 RES MF 22.1 OHM 1% 1/4W 144554
R57 RES MF 22.1K OHM 1% 1/4W 144564
R58 RES NETWORK 2X220K ISO 144678
R59 RES MF 95.3 OHM 1% 1/4W 144572
R60 RES MF 95.3 OHM 1% 1/4W 144572
R61 RES MF 1K 1% 1/4W 144513
R62 RES MF 47.5K 1% 1/4W 144526
R63 RES MF 47.5K 1% 1/4W 144526
R64 RES MF 7.5K OHM 0.5% 1/4W 144605
R65 RES MF 7.5K OHM 0.5% 1/4W 144605
R66 RES MF 89.8K 0.5% 1/4W 144606
R67 RES MF 89.8K 0.5% 1/4W 144606
R68 RES MF 47.5 OHM 1% 1/4W 144642
R69 RES MF 2.21 OHM 1% 1/4W 144607
R70 RES MF 47.5 OHM 1% 1/4W 144642
R71 RES MF 2.21 OHM 1% 1/4W 144607
R72 RES MF 22.1 OHM 1% 1/4W 144554
U1 IC REGULATOR 15V 133589
U2 IC REGULATOR -15V 133588
U3 IC REGULATOR 5V 1.5A LOW DROP 133610
U4 IC NAND 2 INPUT X 4 133575
U5 IC PROGRAMMED V1.00 MA6300 133563
(U5) SOCKET IC 40-PIN 178133
U6 IC MICRO RESET POS 133241
U7 IC AND 2 INPUT X 4 133577
U8 IC SHFT REG SER-PAR 133594
U9 IC SHFT REG SER-PAR 133594
U10 IC SHFT REG SER-PAR 133594
U11 IC OCTAL DAR TRNS ARRY W/DIODE 133624
U12 IC 8 LN DRIVER ARRAY 133180
U13 IC DUAL OPERATIONAL AMPLIFIER 133578
U14 IC DUAL OPERATIONAL AMPLIFIER 133578
U15 IC OPERATIONAL AMP LOW NOISE 133565
U16 IC OPERATIONAL AMP LOW NOISE 133565
Y1 CERAMIC RESONATOR 12MHZ 180059
