McIntosh MA6300

MA6300
39
PARTS LIST cont’d.
PREAMP PCB 050279
Ref No. Description Part No.
Ref No. Description Part No.
C1 CAP ELECT 220UF 25V 066507
C2 CAP ELECT 47UF 25V 20% BP 066556
C3 CAP MPF 0.22UF 5% 63VDC 064329
C4 CAP MPF 0.22UF 5% 63VDC 064329
C5 CAP MONO 100PF 100V 10% NPO 061341
C6 CAP MONO 100PF 100V 10% NPO 061341
C7 CAP MONO 100PF 100V 10% NPO 061341
C8 CAP MONO 100PF 100V 10% NPO 061341
C9 CAP MONO .1UF 50V 20% Z5U 061346
C10 CAP MONO 100PF 100V 10% NPO 061341
C11 CAP MONO 100PF 100V 10% NPO 061341
C12 CAP MONO .1UF 50V 20% Z5U 061346
C13 CAP ELECT 47UF 35V 066446
C14 CAP ELECT 47UF 35V 066446
C15 CAP MPF 0.22UF 5% 63VDC 064329
C16 CAP MPF 0.22UF 5% 63VDC 064329
C17 CAP MPF 0.22UF 5% 63VDC 064329
C18 CAP MPF 0.22UF 5% 63VDC 064329
C19 CAP MONO .1UF 50V 20% Z5U 061346
C20 CAP MONO .1UF 50V 20% Z5U 061346
C21 CAP ELECT 22UF 100V 066574
C22 CAP ELECT 22UF 100V 066574
C23 CAP ELECT 100UF 25V 066447
C24 CAP ELECT 100UF 25V 066447
C25 CAP MONO .1UF 50V 20% Z5U 061346
C29 CAP MONO 220PF 200V 10% 061342
C30 CAP MONO 220PF 200V 10% 061342
C26 CAP MONO .1UF 50V 20% Z5U 061346
C27 CAP ELECT 10UF 50V 066445
C28 CAP ELECT 10UF 50V 066445
D1 DIODE SILICON 070174
J1 CONN 12 PIN FFC 117720
J2 CONN 12 PIN FFC 117720
J3 CONN 12 PIN FFC 117720
J4 CONN 12 PIN FFC 117720
J5 CONN 12 PIN FFC 117720
J6 CONN 12 POS MALE RT ANGLE 117816
K1 RELAY REED SPST-NO 5V 1.2A 087078
PCB1 PC BD PREAMP 129607
R1 RES MF 1.5K 1% 1/4W 144539
R2 RES MF 1.5K 1% 1/4W 144539
R3 RES MF 10 OHM 1% 1/4W 144553
R4 RES MF 10 OHM 1% 1/4W 144553
R5 RES MF 10 OHM 1% 1/4W 144553
R6 RES MF 4.75K 1% 1/4W 144520
R7 RES MF 4.75K 1% 1/4W 144520
R8 POT 50KAX2 134490
R9 RES MF 187K 1% 1/4W 144621
R10 RES MF 1K 1% 1/4W 144513
R11 RES MF 1K 1% 1/4W 144513
R12 RES MF 187K 1% 1/4W 144621
R13 RES MF 1.5K 1% 1/4W 144539
R14 RES MF 1.5K 1% 1/4W 144539
R15 RES MF 4.75K 1% 1/4W 144520
R16 RES MF 4.75K 1% 1/4W 144520
R17 POT BALANCE 2KOHM 134464
R18 RES MF 121K 1% 1/4W 144626
R19 RES MF 121K 1% 1/4W 144626
R20 RES MF 47.5K 1% 1/4W 144526
R21 RES MF 47.5K 1% 1/4W 144526
R22 RES MF 33.2K 1% 1/4W 144694
R23 RES MF 33.2K 1% 1/4W 144694
R24 RES MF 47.5 OHM 1% 1/4W 144642
R25 RES MF 47.5 OHM 1% 1/4W 144642
R26 RES MF 221 OHM 1% 1/4W 144559
R27 RES MF 221 OHM 1% 1/4W 144559
R28 RES MF 4.99K 1% 1/4W 144521
R29 RES MF 4.99K 1% 1/4W 144521
R30 RES MF 1K 1% 1/4W 144513
R31 RES MF 1K 1% 1/4W 144513
R32 RES MF 100 OHM 1% 1/4W 144568
R33 RES MF 100 OHM 1% 1/4W 144568
U1 IC DC MOTOR DRIVER 133191
U2 IC DUAL OPERATIONAL AMPLIFIER 133260
U3 IC DUAL OPERATIONAL AMPLIFIER 133260
U4 IC DUAL OPERATIONAL AMPLIFIER 133260
HEATSINK PCB 050280
C1 CAP ELECT 10UF 100VDC 066462
C2 CAP ELECT 10UF 100VDC 066462
C3 CAP MONO .1UF 50V 20% Z5U 061346
C4 CAP MONO .1UF 50V 20% Z5U 061346
C5 CAP ELECT 10UF 100VDC 066462
C6 CAP ELECT 10UF 50V 066445
C7 CAP ELECT 10UF 100VDC 066462
C8 CAP ELECT 100UF 25V 066573
C9 CAP ELECT 10UF 50V 066445
C10 CAP ELECT 10UF 50V 066445
C11 CAP MONO 100PF 100V 10% NPO 061341
C12 CAP MONO 100PF 100V 10% NPO 061341
C13 CAP ELECT 220UF 25V 066507
C14 CAP MONO 100PF 100V 10% NPO 061341
C15 CAP MONO .01UF 50V 20% X7R 061345
C16 CAP ELECT 22UF 100V 066574
C17 CAP ELECT 22UF 100V 066574
C18 CAP MONO .01UF 50V 20% X7R 061345
C19 CAP MONO .1UF 50V 20% Z5U 061346
C20 CAP MONO 100PF 100V 10% NPO 061341
C21 CAP MONO 100PF 100V 10% NPO 061341
C22 CAP MONO .1UF 50V 20% Z5U 061346
C23 CAP POLYPROP .047UF 10% 250VDC 064364
C24 CAP MONO .1UF 50V 20% Z5U 061346
C25 CAP ELECT 10UF 50V 066445
C26 CAP ELECT 10UF 50V 066445
C27 CAP MONO 100PF 100V 10% NPO 061341
C28 CAP MONO 100PF 100V 10% NPO 061341
C29 CAP ELECT 220UF 25V 066507
C30 CAP MONO 100PF 100V 10% NPO 061341
C31 CAP MONO .01UF 50V 20% X7R 061345
C32 CAP ELECT 22UF 100V 066574
C33 CAP ELECT 22UF 100V 066574
C34 CAP MONO .01UF 50V 20% X7R 061345
C35 CAP MONO .1UF 50V 20% Z5U 061346
C36 CAP MONO 100PF 100V 10% NPO 061341
C37 CAP MONO 100PF 100V 10% NPO 061341
C38 CAP MONO .1UF 50V 20% Z5U 061346
C39 CAP POLYPROP .047UF 10% 250VDC 064364
C40 CAP MONO .1UF 50V 20% Z5U 061346
