McIntosh MA6300

40
PARTS LIST cont’d.
HEATSINK PCB 050280 (Cont’d.)
Ref No. Description Part No.
Ref No. Description Part No.
D1 DIODE SILICON 070174
D2 DIODE SILICON 070174
D3 DIODE SILICON 070174
D4 DIODE SILICON 070174
D5 DIODE SILICON 070174
D6 DIODE SILICON 070174
D7 DIODE SILICON 070174
D8 DIODE SILICON 070174
D9 DIODE SILICON 070174
D10 DIODE SILICON 070174
D11 DIODE SILICON 070174
GP1 STANDOFF 6-32 X 1/4 MOUNT PCB 112130
GP2 STANDOFF 6-32 X 1/4 MOUNT PCB 112130
J7 J8 CONN 2 PIN MALE 117213
J2 CONN 3 POS MALE LARGE FRCTN LK 117293
J5 J6 CONN HEADER 2 PIN 0.156 117404
J1 BLADE FASTON W/FEET 117708
J3 J4 CONN 12 PIN FFC 117720
K1 RELAY 12VDC 5A 250VAC TV-4 087077
L1 L2 CHOKE 0.65UH OUTPUT 122297
PCB1 PD BD HEATSINK 129608
Q1 TRANSISTOR NPN 2K/REEL 132317
Q2 TRANSISTOR NPN 2K/REEL 132317
Q3 TRANSISTOR PNP 132304
Q4 TRANSISTOR PNP 132304
Q5 TRANSISTOR PNP 132304
Q6 TRANSISTOR PNP 132304
Q7 TRANSISTOR PNP 132304
Q8 TRANSISTOR NPN 2K/REEL 132317
Q9 TRANSISTOR N JFET 132318
Q10 TRANSISTOR PNP 132304
Q11 TRANSISTOR PNP 132304
Q12 TRANSISTOR NPN 132254
Q13 TRANSISTOR PNP 120V 132255
Q14 TRANSISTOR NPN 132254
Q15 TRANSISTOR PNP 120V 132255
Q16 TRANSISTOR NPN 2K/REEL 132317
Q17 TRANSISTOR PNP 132304
Q18 TRANSISTOR NPN 132254
Q19 TRANSISTOR PNP 120V 132255
Q20 TRANSISTOR NPN 2K/REEL 132317
Q21 TRANSISTOR PNP 132304
Q22 TRANSISTOR PNP 132321
Q23 TRANSISTOR NPN 132322
Q24 TRANSISTOR NPN 2K/REEL 132317
Q25 TRANSISTOR PNP 132304
Q28 TRANSISTOR NPN 2K/REEL 132317
Q29 TRANSISTOR NPN 132322
Q30 TRANSISTOR PNP 132321
Q35 TRANSISTOR NPN 2K/REEL 132317
Q36 TRANSISTOR N JFET 132318
Q37 TRANSISTOR PNP 132304
Q38 TRANSISTOR PNP 132304
Q39 TRANSISTOR NPN 132254
Q40 TRANSISTOR PNP 120V 132255
Q41 TRANSISTOR NPN 132254
Q42 TRANSISTOR PNP 120V 132255
Q43 TRANSISTOR NPN 2K/REEL 132317
Q44 TRANSISTOR PNP 132304
Q45 TRANSISTOR NPN 132254
Q46 TRANSISTOR PNP 120V 132255
Q47 TRANSISTOR NPN 2K/REEL 132317
Q48 TRANSISTOR PNP 132304
Q49 TRANSISTOR PNP 132321
Q50 TRANSISTOR NPN 132322
Q51 TRANSISTOR NPN 2K/REEL 132317
Q52 TRANSISTOR PNP 132304
Q55 TRANSISTOR NPN 2K/REEL 132317
Q56 TRANSISTOR NPN 132322
Q57 TRANSISTOR PNP 132321
R1 RES FP 10 OHM 5% 1/4W 137105
R2 RES FP 10 OHM 5% 1/4W 137105
R3 RES MET OX 47 OHM 5% 1/2W 137102
R4 RES MET OX 47 OHM 5% 1/2W 137102
R6 RES MF 4.75K 1% 1/4W 144520
R5 RES MF 47.5K 1% 1/4W 144526
R7 RES MF 47.5K 1% 1/4W 144526
R8 RES MF 22.1K 1% 1/4W 144564
R9 RES MF 22.1K 1% 1/4W 144564
R10 RES MF 6.49K 1% 1/4W 144617
R11 RES MF 22.1K 1% 1/4W 144564
R12 RES MF 6.49K 1% 1/4W 144617
R13 RES MF 10K 1% 1/4W 144504
R14 RES MF 22.1K 1% 1/4W 144564
R15 RES MF 10K 1% 1/4W 144504
R16 RES MF 15K 1% 1/4W 144623
R17 RES MF 15K 1% 1/4W 144623
R18 RES MF 10K 1% 1/4W 144504
R19 RES MF 10K 1% 1/4W 144504
R20 RES MF 40.2K 1% 1/4W 144525
R21 RES MF 267K 1% 1/4W 144532
R22 RES MF 267K 1% 1/4W 144532
R23 RES MF 499 OHM 1% 1/4W 144510
R24 RES MF 475 OHM 1% 1/4W 144509
R25 RES MF 499 OHM 1% 1/4W 144510
R26 RES MF 267K 1% 1/4W 144532
R27 RES MF 10K 1% 1/4W 144504
R28 RES MF 681K 1% 1/4W 144643
R29 RES MF 47.5K 1% 1/4W 144526
R30 RES MF 499 OHM 1% 1/4W 144510
R31 RES MF 2.74K 1% 1/4W 144587
R32 RES MF 1.1K 1% 1/4W 144514
R33 RES MF 1K 1% 1/4W 144513
R34 RES MF 2.74K 1% 1/4W 144587
R35 RES MF 475K 1% 1/4W 144604
R36 RES MF 15K 1% 1/4W 144623
R37 RES MF 221K 1% 1/4W 144629
R38 RES MF 221 OHM 1% 1/4W 144559
R39 RES MF 221 OHM 1% 1/4W 144559
R40 RES MF 806 OHM 1% 1/4W 144512
R41 RES MF 806 OHM 1% 1/4W 144512
R42 RES MF 22.1K 1% 1/4W 144564
R43 RES MF 22.1K 1% 1/4W 144564
R44 RES MET OX 1.8K 5% 1/2W 137100
R45 RES MET OX 1.8K 5% 1/2W 137100
R47 RES MET OX 1.8K 5% 1/2W 137100
R47 RES MF 1.5K 1% 1/4W 144539
R48 POT TRIM 500 OHM 20% HORIZ ADJ 134410
R49 RES MET OX 1.8K 5% 1/2W 137100
R50 RES MET OX 47 OHM 5% 1/2W 137102
