McIntosh MA6300

R8 RES MF 324 OHM 1% 1/4W 144597
R9 RES MF 324 OHM 1% 1/4W 144597
R10 RES MF 324 OHM 1% 1/4W 144597
R11 RES MF 15K 1% 1/4W 144623
R12 RES MF 15K 1% 1/4W 144623
R13 RES MF 324 OHM 1% 1/4W 144597
R14 RES MF 15K 1% 1/4W 144623
R15 RES MF 15K 1% 1/4W 144623
R16 RES MF 324 OHM 1% 1/4W 144597
R17 RES MF 4.75K 1% 1/4W 144520
R18 RES MF 4.75K 1% 1/4W 144520
R19 RES MF 221K 1% 1/4W 144629
R20 RES MF 221K 1% 1/4W 144629
R21 RES MF 8.25K OHM 1% 1/4W 144549
R22 RES MF 8.25K OHM 1% 1/4W 144549
R23 RES MF 2.21M 1/4W 144576
R24 RES MF 2.21M 1/4W 144576
R25 RES MF 2.21M 1/4W 144576
R26 RES MF 221K 1% 1/4W 144629
R27 RES MF 221K 1% 1/4W 144629
R28 POT TRIM 100K OHM 20% 134383
R29 POT TRIM 100K OHM 20% 134383
R30 RES MF 221 OHM 1% 1/4W 144559
R31 RES MF 221 OHM 1% 1/4W 144559
R32 RES MF 2.21M 1/4W 144576
R33 RES MF 1M 1/4W 144577
R34 RES MF 2.21M 1/4W 144576
R35 RES MF 1M 1/4W 144577
R36 RES MF 4.75K 1% 1/4W 144520
R37 RES MF 4.75K 1% 1/4W 144520
R38 POT TRIM 500 OHM 20% HORIZ ADJ 134410
R39 POT TRIM 500 OHM 20% HORIZ ADJ 134410
R40 POT TRIM 500 OHM 20% HORIZ ADJ 134410
R41 POT TRIM 500 OHM 20% HORIZ ADJ 134410
R42 RES MF 100 OHM 1% 1/4W 144568
R43 RES MF 324 OHM 1% 1/4W 144597
U1 IC SHFT REG SER-PAR 133186
U2 IC SHFT REG SER-PAR 133186
U3 IC 8 LN DRIVER ARRAY 133180
U4 IC DUAL OPERATIONAL AMPLIFIER 133260
U5 IC DUAL OPERATIONAL AMPLIFIER 133260
LED SPACER .220 LENGTH 163001
MA6300
42
PARTS LIST cont’d.
DISPLAY PCB 050277 (Cont’d.)
Ref No. Description Part No.
Ref No. Description Part No.
DS1 LED SQUARE RED 058109
(DS1) LED SPACER .220 LENGTH 163001
DS2 LED SQUARE RED 058109
(DS2) LED SPACER .220 LENGTH 163001
DS3 LED SQUARE RED 058109
(DS3) LED SPACER .220 LENGTH 163001
DS4 LED SQUARE RED 058109
(DS4) LED SPACER .220 LENGTH 163001
DS5 LED SQUARE RED 058109
(DS5) LED SPACER .220 LENGTH 163001
DS6 LED SQUARE RED 058109
(DS6) LED SPACER .220 LENGTH 163001
DS7 LED SQUARE RED 058109
(DS7) LED SPACER .220 LENGTH 163001
DS8 LED SQUARE RED 058109
(DS8) LED SPACER .220 LENGTH 163001
DS9 LED SQUARE RED 058109
(DS9) LED SPACER .220 LENGTH 163001
DS10 LED SQUARE RED 058109
(DS10) LED SPACER .220 LENGTH 163001
TUBING SHRINK 1/4ID BLK 077041
J1 CONN 12 PIN FFC 117720
J2 CONN 12 PIN FFC 117720
PCB1 PC BD PUSHBUTTON 129667
S1 SWITCH TACT 150058
S2 SWITCH TACT 150058
S3 SWITCH TACT 150058
S4 SWITCH TACT 150058
S5 SWITCH TACT 150058
S6 SWITCH TACT 150058
S7 SWITCH TACT 150058
S8 SWITCH TACT 150058
S9 SWITCH TACT 150058
S10 SWITCH TACT 150058
6
PUSHBUTTON PCB 050278
