TM2-6
Rear Panel Connections
75 OHM FM ANT
(Antenna) connects
to an external FM
Antenna or cable
AM ANT (Antenna) con-
nector allows a McIntosh
RAA2 Remote Antenna
to be connected
McIntosh TM2
HD AM/FM Tuner
Module
McIntosh RAA2 External
AM Antenna
Connect to the TM2
HD AM/FM Tuner
Module with the sup-
plied shielded cable
