McIntosh MA6900 Owner's Manual

11
How to Connect for a Second Room
How to Connect for a Second Room
1. Connect Audio Cables from the MA6900 OUTPUTS 2
to the Second Power Amplifier Inputs.
2. Connect Hookup Cables from the Second Power Am-
plifier to the loudspeakers. Refer to page 8 in this
Owner’s Manual for connection details.
3. Connect a Control Cable from the MA6900 POWER
CONTROL 2 Jack to the Power Control In of a McIn-
tosh Power Amplifier.
4. Connect an RG6 or RG59U coaxial cable from the
EXTernal SENSOR Jack to a Keypad.
Note: A Wall Mounted IR Sensor may also be used in place
of the keypad.
Right
Loudspeaker
4 ohm
Left
Loudspeaker
4 ohm
McIntosh Power Amplifier
Keypad

McIntosh MA6900 Specifications

General

Total Harmonic Distortion	0.005%
Signal to Noise Ratio	100dB
Input Impedance	20k ohms
Damping Factor	>40
Outputs	preamp outputs
Weight	75 lbs (34 kg)
Input Sensitivity	2.5mV (MM phono), 0.25V (line)
Output Impedance	2, 4 or 8 Ohms
Frequency Response	20Hz to 20kHz (+0 -0.5dB)
Inputs	6 line-level inputs (including balanced), 1 phono input
