26
The Front Panel Display indicates the Bass changes
in steps from +12dB to -12dB. After approximately
6 seconds the Display returns to indicate the Source
Selection and Volume Level.
TREBLE
The Intensity of the High Frequencies in the music can
be increased or decreased by using the Trim Select
and Trim Adjust Control. To make an adjustment per-
form the following:
1. Use the Front Panel INPUT/TRIM Control or the
TRIM Push-button on the Remote Control until
“TREBLE, 0 dB” appears on the Front Panel
Information Display. Refer to figure 65.
2. Rotate the VOLUME/ADJUST Control or press
the LEVEL UP / DOWN Push-buttons to increase
3. Rotate the VOLUME/Adjust Control or press the
LEVEL UP / DOWN Push-buttons on the Remote
Control to select the Resistance Load that comes
closest to the Phono Cartridge Makers recom-
mended value.
After approximately 5 seconds the Alphanumeric
Display returns to indicate the Source Selection and
Volume Level.
MONO/STEREO MODE
By default the Stereo Mode is active for all Input
Sources however, any Input Source may be assigned
to Mono Mode. To change Stereo Mode to Mono for a
given Input Source, perform the following steps:
1. Select the desired Input Source.
2. Select “MONO / STEREO,
______
” as
indicated on the Front Panel Information Display.
Refer to figure 69.
3. To select MONO Mode adjust the TRIM LEVEL.
Refer to figure 70.
After approximately 5 seconds the Information
Display returns to indicate the Source Selection and
Volume Level.
(refer to figure 66) or decrease (refer to figure 67)
the volume level of the high frequencies.
The Front Panel Display indicates the Treble changes
in steps from +12dB to -12dB. After approximately
6 seconds the Display returns to indicate the Source
Selection and Volume Level.
PHONO ADJUSTMENTS
When the MC Phono Input is selected, an additional
TRIM SELECT FUNCTION becomes available for
adjustment. Perform the following steps to make the
Phono Trim Adjustment:
1. Select the MC Phono Source Input.
2. Select TRIM “PHONO RESISTANCE, 400Ω” as
indicated on the Front Panel Information Display.
Refer to figure 68.
Figure 50
How to Operate the MA7200, con’t
Figure 70
____
Figure 69
Figure 64
-12dB
Figure 65
0 dB
Figure 66
+12dB
Figure 67
-12dB
USB 35%
DSD256
Figure 68
O
