McIntosh MA7900 User Manual

10
The MA7900 can be part of a Multichannel Sound
System for SACD, DVD-Audio and Home Theater.
The Right and Left Front Channels from an Audio/
Video Control Center can “Passthru” the MA7900. In
the following example the SRVR Input will become
the “Passthru” input:
1. Connect Audio Cables from the A/V Control
Center Front Left and Right Channel Outputs to
the MA7900 SRVR Input Left and Right Jacks.
2. Connect a Control Cable from the A/V Control
Center ZA (Zone A) PC (Power Control) Output
to the MA7900 PWR CTRL (Power Control)
PASSTHRU Input Jack.
Note: Refer to Setup “Passthru” on page 20 to assign
the SRVR Input as the “Passthru” Input.
3. Proceed to “Connecting Loudspeaker” on
Page 12.
Passthru Connections
Passthru Connections
A/V Control Center
