PARTS LIST con’t

750760 DRIVER PCB

Ref. No. Description Part No.

C1 CAP MONO .1UF 50V 20% 061346

C2 CAP MONO 470PF 100V 5% NPO 061343

C3 CAP MONO 470PF 100V 5% NPO 061343

C4 CAP MONO 470PF 100V 5% NPO 061343

C5 CAP MONO 100PF 100V 10% NPO 061341

C6 CAP MONO 100PF 100V 10% NPO 061341

C7 CAP MONO 100PF 100V 10% NPO 061341

C8 CAP MONO 100PF 100V 10% NPO 061341

C9 CAP MONO 470PF 100V 5% NPO 061343

C10 CAP MONO .1UF 50V 20% 061346

C11 CAP ELECT 10UF 100VDC 066462

C12 CAP ELECT 10UF 100VDC 066462

C14 CAP ELECT 10UF 100VDC 066462

C15 CAP ELECT 47UF 35V 066446

C16 CAP ELECT 10UF 100VDC 066462

C19 CAP ELECT 10UF 100VDC 066462

C21 CAP ELECT .47UF 50V 20% 066244

C27 CAP MONO 470PF 100V 5% NPO 061343

C28 CAP MONO 470PF 100V 5% NPO 061343

C32 CAP POLYPROP 0.15UF 10% 250VDC 064464

C33 CAP POLYPROP 0.15UF 10% 250VDC 064464

C34 CAP POLYPROP 0.15UF 10% 250VDC 064464

C35 CAP POLYPROP 0.15UF 10% 250VDC 064464

C36 CAP MPF 0.01UF 5% 63VDC 064312

C37 CAP MPF 0.01UF 5% 63VDC 064312

C39 CAP MPF 0.022UF 5% 63VDC 064316

C43 CAP DISC 1.8PF+/-.25PF NPO 061356

C41 CAP ELECT 220UF 25V 066507

J1 CONN MALE 7 PIN 117217

J2 CONN 4 PIN 117215

J3 CONN MALE 7 PIN 117217

J4 CONN 4 PIN 117215

J6 CONN 11 POS MALE 117279

J7 CONN MALE 10 POS 117219

J9 CONN 4 PIN 117215

LDR1 LDR NETWORK 144179

PCB1 PC BD DRIVER 129863

Q1 TRANSISTOR PNP SILICON 132304

Q7 TRANSISTOR N JFET 132319

Q8 TRANSISTOR N JFET 132319

Q10 TRANSISTOR N JFET 132319

Q11 TRANSISTOR N JFET 132319

Q12 TRANSISTOR NPN SILICON 132317

Q13 TRANSISTOR NPN SILICON 132317

Q14 TRANSISTOR SI NPN 132254

Q15 TRANSISTOR PNP 132255

Q16 TRANSISTOR PNP SILICON 132304

Q17 TRANSISTOR NPN SILICON 132317

Q18 TRANSISTOR SI NPN 132254

Q19 TRANSISTOR NPN SILICON 132317

Q20 TRANSISTOR PNP SILICON 132304

Q21 TRANSISTOR PNP 132255

Q22 TRANSISTOR PNP SILICON 132304

Q23 TRANSISTOR PNP SILICON 132304

Q36 TRANSISTOR NPN SILICON 132317

Q37 TRANSISTOR PNP SILICON 132304

Q38 TRANSISTOR PNP SILICON 132304

Q39 TRANSISTOR PNP SILICON 132304

Q41 TRANSISTOR PNP 2SA1321C 132326

Q42 TRANSISTOR PNP 2SA1321C 132326

Q55 TRANSISTOR NPN 2SC3334C 132325

Q56 TRANSISTOR NPN 2SC3334C 132325

Q60 TRANSISTOR SI NPN 132254

Q61 TRANSISTOR PNP 132255

Q62 TRANSISTOR PNP 132255

Q63 TRANSISTOR SI NPN 132254

Q64 TRANSISTOR SI NPN 132254

Q66 TRANSISTOR PNP SILICON 132304

Q67 TRANSISTOR NPN SILICON 132317

Q68 TRANSISTOR PNP 132255

Q72 TRANSISTOR PNP 132255

Q75 TRANSISTOR SI NPN 132254

Q78 TRANSISTOR NPN SILICON 132317

R1 RES MF 1K 1% 1/4W 144513

R2 RES MF 1K 1% 1/4W 144513

R3 RES MF 1K 1% 1/4W 144513

R4 RES MF 1K 1% 1/4W 144513

R5 RES MF 100 OHM 1% 1/4W 144568

R27 RES MET OX 47 OHM .5W 5% 137102

R30 RES MF 866 OHM 1% 1/4W 144503

R31 RES MF 221 OHM 1% 1/4W 144559

R32 RES MF 22.1K 1% 1/4W 144564

R33 RES MF 475K 1% 1/4W 144604

R34 RES MF 2.21M 1/4W 144576

R35 RES MF 1.5K 1% 1/4W 144539

R36 RES MF 6.49K .5% 1/4W 144617

R37 RES MF 1.5K 1% 1/4W 144539

R38 RES MF 5.36K .5% 1/4W 144615

R39 RES MF 150K 1% 1/4W 144627

R40 RES MF 2.21M 1/4W 144576

R41 RES MF 365 OHM 1% 1/4W 144505

R42 RES MF 324 OHM 1% 1/4W 144597

R43 RES MF 324 OHM 1% 1/4W 144597

R44 RES MF 324 OHM 1% 1/4W 144597

R45 RES MF 324 OHM 1% 1/4W 144597

R46 RES MF 324 OHM 1% 1/4W 144597

R47 RES MF 324 OHM 1% 1/4W 144597

R48 RES MF 324 OHM 1% 1/4W 144597

R49 RES MF 221 OHM 1% 1/4W 144559

R50 RES MF 5.36K .5% 1/4W 144615

R51 RES MF 6.49K .5% 1/4W 144617

R53 RES MF 3.32K 1% 1/4W 144518

R54 RES MF 267 OHM 1% 1/4W 144560

R55 RES MF 475K 1% 1/4W 144604

R56 RES MF 267 OHM 1% 1/4W 144560

R57 RES MF 866 OHM 1% 1/4W 144503

R58 RES MF 4.75K 1% 1/4W 144520

R59 RES MF 150K 1% 1/4W 144627

R60 RES MF 1K 1% 1/4W 144513

R61 RES MF 47.5K 1% 1/4W 144526

R62 RES MF 100 OHM 1% 1/4W 144568

R63 RES MF 47.5K 1% 1/4W 144526

R64 RES MF 866 OHM 1% 1/4W 144503

R67 RES MF 324 OHM 1% 1/4W 144597

R68 RES MF 681K 1% 1/4W 144643

R69 RES MF 3.32K 1% 1/4W 144518

R70 RES MF 681K 1% 1/4W 144643

R71 RES MF 365 OHM 1% 1/4W 144505

R72 RES MF 3.32K 1% 1/4W 144518

R74 RES MET OX 47 OHM .5W 5% 137102
