PERFORMANCE LIMITS
POWER OUTPUT
1000 watts into 8, 4 or 2 ohm load is the
minimum sine wave continuous average
power output.
The output RMS voltage is:
89.4 volts across 8 ohms
63.2 volts across 4 ohms
44.7 volts across 2 ohms
OUTPUT LOAD IMPEDANCE
Terminals for 8, 4 and 2 ohms
RATED POWER BAND
20Hz to 20,000Hz
TOTAL HARMONIC DISTORTION
0.005% maximum harmonic distortion at
any power level from 250 milliwatts to rated
power output.
DYNAMIC HEADROOM
2.1dB
FREQUENCY RESPONSE
+ 0, -0.25dB from 20Hz to 20,000Hz
+ 0, -3.0dB from 10Hz to 100,0OOHz
INPUT SENSITIVITY
2.5 volts
A-WEIGHTED SIGNAL-TO-NOISE RATIO
Balanced, 90dB (120dB below rated
output)
Unbalanced, 85dB (115dB below rated
output)
INTERMODULATION DISTORTION, SMPTE
0.005% maximum if instantaneous peak
power output does not exceed twice the out-
put rating.
RATINGS
WIDE BAND DAMPING FACTOR
200 at 8 ohm output
INPUT IMPEDANCE
10,000 ohms
POWER GUARD
Clipping is prevented and THD does not
exceed 2% with up to 14dB overdrive at
1000Hz.
POWER REQUIREMENTS
120 volts, 50/60HZ, 12 amperes UL/CSA
MECHANICAL
SIZE
17-1/4 inches {43.8cm) wide, by 10-3/8
inches (26.4cm) high, by 20-1/8 inches
(51.1cm) deep, including front handles.
FINISH
Front panel is glass with gold/teal
nomenclature illumination. Handles and side
pieces are gold and black anodized
aluminum. The chassis is chrome.
WEIGHT
105 pounds (47.7Kg) net; 118 pounds
(53.5Kg) in shipping carton.
SPECIFICATIONS
9
