McIntosh MC152 - Front Panel Displays and Controls

12
Front Panel Displays and Controls
Standby Power
On Indicator
POWER Push-button switches
AC Power On and Off
METER Push-button switches
Meter Illumination On and Off
Meter indicates the
Right Channel Output
of the amplifier
LED indicates when the LEFT
Channel Amplifier POWER
GUARD circuit activates
Meter indicates the
Left Channel Output
of the amplifier
LED indicates when the RIGHT
Channel Amplifier POWER
GUARD circuit activates
