AGR 070A through 100A Product Manual AGR-3
Table 21, AGR 090AM - 100AM
PHYSICAL DATA AGR MODEL NUMBER
STANDARD EFFICIENCY 090AM 095AM 100AM
OUTDOOR UNIT BASIC DATA Ckt.1 Ckt.2 Ckt.1 Ckt.2 Ckt.1 Ckt.2
Number Of Refrigerant Circuits 2 2 2
Unit Operating Charge, R-22, lbs.(kg) 90 (40.8) 90 (40.8) 90 (40.8) 90 (40.8) 92 (41.7) 92 (41.7)
Unit Operating Charge, R-134a, lbs.(kg) 94 (42.8) 94 (42.8) 94 (42.8) 94 (42.8) 94 (42.8) 94 (42.8)
Cabinet Dimensions, LxWxH, In. 136.4 x 88.2 x 96.2 136.4 x 88.2 x 96.2 136.4 x 88.2 x 96.2
Cabinet Dimensions, LxWxH, (mm) 3463 x 2241 x 2444 3463 x 2241 x 2444 3463 x 2241 x 2444
Unit Operating Weight, Lbs. (kg) 5858 (2654) 5068 (2296) 5068 (2296)
Unit Shipping Weight, Lbs. (kg) 4933 (2235) 4943 (2239) 4943 (2239)
Add'l Weight If Copper Finned Coils, Lbs. (kg) 1245 (565) 1245 (565) 1245 (565)
COMPRESSORS
Type Semi-Hermetic Semi-Hermetic Semi-Hermetic
Nominal Horsepower 50 50 50 60 60 60
Number Of Cylinders Per Compressor 888888
Oil Charge Per Compressor, oz. 255 255 255 255 255 255
Oil Charge Per Compressor, (g) (7229) (7229) (7229) (7229) (7229) (7229)
CAPACITY REDUCTION STEPS - PERCENT OF COMPRESSOR DISPLACEMENT
Standard Staging - Circuit #1 in Lead 0-25-50-63-75 0-23-50-61-75 0-25-50-63-75
-88-100 -86-100 -88-100
Standard Staging - Circuit #2 in Lead 0-25-50-63-75 0-27-50-64-75 0-25-50-63-75
-88-100 -89-100 -88-100
CONDENSERS - HIGH EFFICIENCY FIN AND TUBE TYPE WITH INTEGRAL SUBCOOLING
Coil Face Area,Sq. Ft. 878787878787
Coil Face Area, (m
2
) (8.1) (8.1) (8.1) (8.1) (8.1) (8.1)
Finned Height x Finned Length, In. 100x125.3 100x125.3 100x125.3 100x125.3 100x125.3 100x125.3
Finned Height x Finned Length, (mm)
2540 x
3183
2540 x
3183
2540 x
3183
2540 x
3183
2540 x
3183
2540 x
3183
Fins Per Inch x Rows Deep 16 x 3 16 x 3 16 x 3 16 x 3 16 x 3 16 x 3
Pumpdown capacity @ 90% Lbs. (kg) 162 (73) 162 (73) 162 (73) 162 (73) 162 (73) 162 (73)
Maximum Relief Valve Pressure Setting, psig (kPa) 450 (3103) 450 (3103) 450 (3103) 450 (3103) 450 (3103) 450 (3103)
CONDENSER FANS - DIRECT DRIVE PROPELLER TYPE
Number Of Fans - Fan Diameter, In. (mm) 6 - 28 (712) 6 - 28 (712) 6 - 28 (712)
Number Of Motors - HP (kW) 6 - 2.0 (1.5) 6 - 2.0 (1.5) 6 - 2.0 (1.5)
Fan And Motor RPM, 60Hz 1140 1140 1140
60 Hz Fan Tip Speed, FPM (M/Sec) 8357 (35.4) 8357 (35.4) 8357 (35.4)
60 Hz Total Unit Airflow, CFM (M3/sec) 61200 (28.9) 61200 (28.9) 61200 (28.9)
REMOTE DIRECT EXPANSION EVAPORATOR - BAFFLED SHELL AND -TUBE
Model Number, CDE 1455-1 1455-1 1455-1
Operating Weight Lbs (kg) 1126 (511) 1126 (511) 1126 (511)
Shipping Weight Lbs (kg) 1025 (465 1025 (465 1025 (465
Diameter, in. - Length, Ft. 14 - 5.5 14 - 5.5 14 - 5.5
Diameter, (mm) - Length, (mm) 356 - 1676 356 - 1676 356 - 1676
Water Volume, Gallons, (L) 21.2 (80.3) 21.2 (80.3) 21.2 (80.3)
Refrigerant Volume, cu. Ft. (cu. m.) 2.33 (.0659) 2.33 (.0659) 2.33 (.0659)
Operating Charge, Per System, Lbs (kg) (Note 1) 5.2 (2.36) 5.2 (2.36) 5.2 (2.36)
Water Side Design Pressure, psig (kPa) 225 (1552) 225 (1552) 225 (1552)
Refrigerant Design Pressure, psig (kPa) 225 (1552) 225 (1552) 225 (1552)
Water Inlet / Outlet Victaulic Connections, In. (mm) 5 (141.3) 5 (141.3) 5 (141.3)
Drain - NPT int, In. (mm) .375 (9.5) .375 (9.5) .375 (9.5)
Vent - NPT int, In. (mm) .375 (9.5) .375 (9.5) .375 (9.5)
NOTES:
1. Includes evaporator. Does not include suction and liquid line charge. Outdoor unit and evaporator are shipped with
R-22 holding charge.
