Product Manual AGR-3 AGR 070A through 100A
45
Liquid Line Components
To assist in laying out and specifying split systems, the following recommended (or equal) components
can be used.
Table 22, Liquid Line Components for Dual Independent Refrigerant Circuits
Sporlan Part Number Shown - (Equivalents Are Acceptable)
Unit
Model
Refrigerant
Circuit
Nom.R-22
mbh
Filter
Drier
Solenoid
Valve
Sight
Glass
Expansion
Valve
AGR 070AM #1 & #2 460 C-487 E25S270 SA-195 Y-979
AGR 075AM #1 & #2 480 C-487 E25S270 SA-19S OVE-40
#1 490 C-487 E25S270 SA-19S OVE-40
AGR 080AM
#2 589 C-969 E25S290 SA-19S OVE-55
AGR 085AM #1 & #2 589 C-969 E25S290 SA-19S OVE-55
#1 589 C-969 E25S290 SA-19S OVE-55
AGR 095AM
#2 689 C-969 E25S290 SA-19S OVE-55
AGR 100AM #1 & #2 689 C-969 E25S290 SA-19S OVE-55
