McQuay AGR 100AS - Keypad Key Functions; Category Group; Menu Group; Item Group

IOMM AGR-1 AGR 070A through 100A 77
Table 22, MENU 1 Chiller Status
Screen Display
OFF: Manual Mode
OFF: System Sw
OFF: Remote Comm
OFF: Remote Sw
OFF: Time Clock
OFF: Alarm
OFF: PumpDnSw's
Starting
WaitForFlow
WaitForLoad
StageUp
StageDn
Stage
1
Manual
2 InterStg=xxx sec
Table 23, MENU 2 Circ #1 Status
Screen Display
OFF: SystemSw
OFF: ManualMde
OFF: Alarm
OFF: PumpDwnSw
OFF: CycleTime xx
OFF: Ready
PumpingDown
OpenSolenoid
% Capacity
Starting
LowAmbStart
1
Table 24, MENU 3 Circ #2 Status
Screen Display
OFF: SystemSw
OFF: ManualMde
OFF: Alarm
OFF: PumpDwnSw
OFF: CycleTime xx
OFF: Ready
PumpingDown
OpenSolenoid
% Capacity
Starting
LowAmbStart
1
Table 25, MENU 4 Water Temp's
Screen Display
Lvg Evap= xxx.x °F (°C)
Short °F (°C)1
Open °F (°C)
Ent Evap= xxx.x °F (°C)
Short °F (°C)2
Open °F (°C)
D-T Evap
Short °F (°C)3
Open °F (°C)
4
Table 26, MENU 5 Circ #1 Pres's
Screen Display
Evap= xxx.x psi(kPa) xx°F (°C)
Evap 145 +psi(kPa) **°F (°C)
Open N/A ** °F (°C)
1
Short N/A **F
Cond xxx.x psi (kPa) xxx°
Cond 450+ psi (kPa) xxx°
Open N/A ** °F (°C)
2
Short N/A **F
3 MinCondPr = 0#
4 MaxCondPr = 0#
5 LiftD_P= psi
6 Cond Fan Stage = x
Table 27, MENU 6 Circ #2 Pres's
Screen Display
Evap= xxx.x psi(kPa) xx°F (°C)
Evap 145 +psi(kPa) **°F (°C)
Open N/A ** °F (°C)
1
Short N/A **F
Cond xxx.x psi (kPa) xxx°
Cond 450+ psi (kPa) xxx°
Open N/A ** °F (°C)
2
Short N/A **F
3 MinCondPr = 0#
4 MaxCondPr = 0#
5 LiftD_P= psi
6 Cond Fan Stage = x
Menus for the AGR MicroTech Controller
