Table 23, AGS 120C – AGS 210C, Compressor and Condenser Fan Motor Amp Draw
RATED LOAD AMPS
AGS
UNIT
SIZE
VOLTS HZ
CIRCUIT #1 CIRCUIT #2
FAN
MOTORS
FLA
(EACH)
NO OF
FAN
MOTORS
L R A
FAN
MOTORS
(EACH)
208 232 232 7.3 8 40.0
230 210 210 6.6 8 40.0
120 380 60 128 128 4.0 8 20.0
460 112 112 3.3 8 20.0
575 85 85 2.4 8 12.8
208 232 232 7.3 10 40.0
230 210 210 6.6 10 40.0
125 380 60 128 128 4.0 10 20.0
460 112 112 3.3 10 20.0
575 85 85 2.4 10 12.8
208 232 267 7.3 8 40.0
230 210 240 6.6 8 40.0
130 380 60 128 145 4.0 8 20.0
460 112 122 3.3 8 20.0
575 85 94 2.4 8 12.8
208 232 267 7.3 10 40.0
230 210 240 6.6 10 40.0
135 380 60 128 145 4.0 10 20.0
460 112 122 3.3 10 20.0
575 85 94 2.4 10 12.8
208 267 267 7.3 8 40.0
230 240 240 6.6 8 40.0
140 380 60 145 145 4.0 8 20.0
460 122 122 3.3 8 20.0
575 94 94 2.4 8 12.8
208 267 267 7.3 10 40.0
230 240 240 6.6 10 40.0
145 380 60 145 145 4.0 10 20.0
460 122 122 3.3 10 20.0
575 94 94 2.4 10 12.8
208 267 312 7.3 8 40.0
230 240 282 6.6 8 40.0
160 380 60 145 178 4.0 8 20.0
460 122 141 3.3 8 20.0
575 94 113 2.4 8 12.8
208 267 312 7.3 12 40.0
230 240 282 6.6 12 40.0
165 380 60 145 178 4.0 12 20.0
460 122 141 3.3 12 20.0
575 94 113 2.4 12 12.8
208 312 312 7.3 10 40.0
230 282 282 6.6 10 40.0
170 380 60 178 178 4.0 10 20.0
460 141 141 3.3 10 20.0
575 113 113 2.4 10 12.8
208 312 312 7.3 12 40.0
230 282 282 6.6 12 40.0
175 380 60 178 178 4.0 12 20.0
460 141 141 3.3 12 20.0
575 113 113 2.4 12 12.8
208 340 340 7.3 10 40.0
230 308 308 6.6 10 40.0
180 380 60 187 187 4.0 10 20.0
460 154 154 3.3 10 20.0
575 123 123 2.4 10 12.8
