IMM AGS-2 37
RATED LOAD AMPS
AGS
UNIT
SIZE
VOLTS HZ
CIRCUIT #1 CIRCUIT #2
FAN
MOTORS
FLA
(EACH)
NO OF
FAN
MOTORS
L R A
FAN
MOTORS
(EACH)
208 340 340 7.3 10 40.0
230 308 308 6.6 10 40.0
190 380 60 187 187 4.0 10 20.0
460 154 154 3.3 10 20.0
575 123 123 2.4 10 12.8
208 340 340 7.3 12 40.0
230 308 308 6.6 12 40.0
195 380 60 187 187 4.0 12 20.0
460 154 154 3.3 12 20.0
575 123 123 2.4 12 12.8
208 340 340 11.0 12 46.0
230 308 308 9.9 12 46.0
210 380 60 187 187 6.0 12 25.0
460 154 154 4.1 12 23.0
575 123 123 3.0 12 20.0
NOTES:
1. Table based on 75°C field wire.
2. Complete notes are on page on page 47.
Table 24, AGS 120C – AGS 210C, Customer Wiring Information With Single-Point Power
WIRING TO STANDARD UNIT POWER BLOCK
WIRING TO OPTIONAL NONFUSED
MOLDED CASE SWITCH IN UNIT
AGS
UNIT
SIZE
VOLTS HZ
TERMINAL SIZE
AMPS
CONNECTOR WIRE RANGE
PER PHASE
(COPPER WIRE ONLY)
SIZE
CONNECTOR WIRE RANGE
PER PHASE
(COPPER WIRE ONLY)
208 800 1/0 – 750 MCM (4/C) 800 1/0 – 500 MCM (3/C)
230 800 1/0 – 750 MCM (4/C) 800 1/0 – 500 MCM (3/C)
120 380 60 400 #6 – 350 MCM (2/c) 400 3/0 – 500 MCM (2/C)
460 400 #6 – 350 MCM (2/c) 400 3/0 – 500 MCM (2/C)
575 400 #6 – 350 MCM (2/c) 250 #6 – 350 MCM (1/C)
208 800 1/0 – 750 MCM (4/C) 800 1/0 – 500 MCM (3/C)
230 800 1/0 – 750 MCM (4/C) 800 1/0 – 500 MCM (3/C)
125 380 60 400 #6 – 350 MCM (2/C) 400 3/0 – 500 MCM (2/C)
460 400 #6 – 350 MCM (2/C) 400 3/0 – 500 MCM (2/C)
575 400 #6 – 350 MCM (2/C) 250 #6 – 350 MCM (1/C)
208 800 1/0 – 750 MCM (4/C) 800 1/0 – 500 MCM (3/C)
230 800 1/0 – 750 MCM (4/C) 800 1/0 – 500 MCM (3/C)
130 380 60 400 #6 – 350 MCM (2/C) 400 3/0 – 500 MCM (2/C)
460 400 #6 – 350 MCM (2/C) 400 3/0 – 500 MCM (2/C)
575 400 #6 – 350 MCM (2/C) 250 #6 – 350 MCM (1/C)
208 800 1/0 – 750 MCM (4/C) 800 1/0 – 500 MCM (3/C)
230 800 1/0 – 750 MCM (4/C) 800 1/0 – 500 MCM (3/C)
135 380 60 400 #6 – 350 MCM (2/C) 400 3/0 – 500 MCM (2/C)
460 400 #6 – 350 MCM (2/C) 400 3/0 – 500 MCM (2/C)
575 400 #6 – 350 MCM (2/C) 250 #6 – 350 MCM (1/C)
208 800 1/0 – 750 MCM (4/C) 800 1/0 – 500 MCM (3/C)
230 800 1/0 – 750 MCM (4/C) 800 1/0 – 500 MCM (3/C)
140 380 60 400 #6 – 350 MCM (2/C) 400 3/0 – 500 MCM (2/C)
460 400 #6 – 350 MCM (2/C) 400 3/0 – 500 MCM (2/C)
575 400 #6 – 350 MCM (2/C) 250 #6 – 350 MCM (1/C)
208 800 1/0 – 750 MCM (4/C) 800 1/0 – 500 MCM (3/C)
230 800 1/0 – 750 MCM (4/C) 800 1/0 – 500 MCM (3/C)
145 380 60 400 #6 – 350 MCM (2/C) 400 3/0 – 500 MCM (2/C)
460 400 #6 – 350 MCM (2/C) 400 3/0 – 500 MCM (2/C)
575 400 #6 – 350 MCM (2/C) 250 #6 – 350 MCM (1/C)
Continued on next page
