38 IMM AGS-2
WIRING TO STANDARD UNIT POWER BLOCK
WIRING TO OPTIONAL NONFUSED
MOLDED CASE SWITCH IN UNIT
AGS
UNIT
SIZE
VOLTS HZ
TERMINAL SIZE
AMPS
CONNECTOR WIRE RANGE
PER PHASE
(COPPER WIRE ONLY)
SIZE
AMPS
CONNECTOR WIRE RANGE
PER PHASE
(COPPER WIRE ONLY)
208 800 1/0 – 750 MCM (4/C) 800 1/0 – 500 MCM (3/C)
230 800 1/0 – 750 MCM (4/C) 800 1/0 – 500 MCM (3/C)
160 380 60 800 1/0 – 750 MCM (4/C) 600 3/0 – 500 MCM (2/C)
460 400 #6 – 350 MCM (2/C) 600 3/0 – 500 MCM (2/C)
575 400 #6 – 350 MCM (2/C) 600 3/0 – 500 MCM (2/C)
208 800 1/0 – 750 MCM (4/C) 800 1/0 – 500 MCM (3/C)
230 800 1/0 – 750 MCM (4/C) 800 1/0 – 500 MCM (3/C)
165 380 60 800 1/0 – 750 MCM (4/C) 600 3/0 – 500 MCM (2/C)
460 400 #6 – 350 MCM (2/C) 600 3/0 – 500 MCM (2/C)
575 400 #6 – 350 MCM (2/C) 600 3/0 – 500 MCM (2/C)
208 1000 1/0 – 750 MCM (4/C) 1200 250 – 500 MCM (4/C)
230 800 1/0 – 750 MCM (4/C) 800 1/0 – 800 MCM (2/C)
170 380 60 800 1/0 – 750 MCM (4/C) 600 3/0 – 500 MCM (2/C)
460 400 #6 – 350 MCM (2/C) 600 3/0 – 500 MCM (2/C)
575 400 #6 – 350 MCM (2/C) 400 3/0 – 500 MCM (2/C)
208 1000 1/0 – 750 MCM (4/C) 1200 250 – 500 MCM (4/C)
230 800 1/0 – 750 MCM (4/C) 800 1/0 – 800 MCM (2/C)
175 380 60 800 1/0 – 750 MCM (4/C) 600 3/0 – 500 MCM (2/C)
460 400 #6 – 350 MCM (2/C) 600 3/0 – 500 MCM (2/C)
575 400 #6 – 350 MCM (2/C) 400 3/0 – 500 MCM (2/C)
208 1000 1/0 – 750 MCM (4/C) 1200 250 – 500 MCM (4/C)
230 1000 1/0 – 750 MCM (4/C) 1200 250 – 500 MCM (4/C)
180 380 60 800 1/0 – 750 MCM (4/C) 600 3/0 – 500 MCM (2/C)
460 400 #6 – 350 MCM (2/C) 600 3/0 – 500 MCM (2/C)
575 400 #6 – 350 MCM (2/C) 400 3/0 – 500 MCM (2/C)
208 1000 1/0 – 750 MCM (4/C) 1200 250 – 500 MCM (4/C)
230 1000 1/0 – 750 MCM (4/C) 1200 250 – 500 MCM (4/C)
190 380 60 800 1/0 – 750 MCM (4/C) 600 3/0 – 500 MCM (2/C)
460 400 #6 – 350 MCM (2/C) 600 3/0 – 500 MCM (2/C)
575 400 #6 – 350 MCM (2/C) 400 3/0 – 500 MCM (2/C)
208 1000 1/0 – 750 MCM (4/C) 1200 250 – 500 MCM (4/C)
230 1000 1/0 – 750 MCM (4/C) 1200 250 – 500 MCM (4/C)
195 380 60 800 1/0 – 750 MCM (4/C) 600 3/0 – 500 MCM (2/C)
460 400 #6 – 350 MCM (2/C) 600 3/0 – 500 MCM (2/C0
575 400 #6 – 350 MCM (2/C) 400 3/0 – 500 MCM (2/C)
208 1000 1/0 – 750 MCM (4/C) 1200 250 – 500 MCM (4/C)
230 1000 1/0 – 750 MCM (4/C) 1200 250 – 500 MCM (4/C)
210 380 60 800 1/0 – 750 MCM (4/C) 600 3/0 – 500 MCM (2/C)
460 400 #6 – 350 MCM (2/C) 600 3/0 – 500 MCM (2/C)
575 400 #6 – 350 MCM (2/C) 400 3/0 – 500 MCM (2/C)
NOTE:
1. Terminal size amps are the maximum amps that the power block is rated for.
2. Complete notes are on page 47.
3. Data based on 75°C wire.
4. (2/C) notation means two cables per conduit.
