5.3 Chiller Menu Structures
5.3.1 Summary Pages
There are 4 pages in [Summary Pages]. Press UP or DOWN for page scrolling. Press ENTER to go into [Main
Menu].
Time and date are shown on top of each page. Beside that, the bottom of each page shows current control unit of the
Chiller.
For example: [00] – Chiller Panel controls Chiller ID 0 currently
[03] – Chiller Panel controls Chiller ID 3 currently
[All] – Chiller Panel controls all Chiller currently
1st page: Display ON/OFF status, Mode Settings and Temperature settings.
01/01/2000 12:00am
Status : ON
Mode : Cooling
Cool Temp : 12.0ºC
00
2
nd
page: Display Compressor status.
01/01/2000 12:00am
Compressor 1 : ON
00
3
rd
page : Display Water In, Water Out, Outdoor Air and Panel temperatures.
01/01/2000 12:00am
Water In : 19.8ºC
Water Out : 25.6ºC
Outdoor Air : 32.2ºC
Panel : 20.5ºC
00
4
th
page : Display Chiller model, Compressor No. and Chiller ID.
01/01/2000 12:00am
Model : Chiller
No. Comp : 1 Comp
Unit No. : 0
00
10
