5.3.2.2.3 Panel Option
Select [Panel Option] in [Settings Menu] and press ENTER to go into this menu.
Backlight : Normal
Buzzer : On
Screen Saver : Disable
Timeout : 5m
Contrast : 50%
Brightness : Medium
Temp Unit : ºC
Operation Menu
MAIN MENU
User can do some miscellaneous settings for the panel. These settings would not affect whole system
performance.
Settings - toggle Backlight
- Alarm Buzzer
- Enable/Disable Screen Saver
- Screen Saver timeout
- Contrast display
- Backlight brightness
- Temperature unit
Press ESC to exit to [Settings Menu].
5.3.2.2.4 Set Panel ID
Select [Set Panel ID] in [Settings Menu] and press ENTER to go into this menu.
Please enter the0
Panel ID...
=> Unit 0
User can assign the ID no. to the panel.
Example: If ID no. 0 has been assigned, the panel acts like Master Panel Unit. It can choose to control each
Chiller in the network.
If other ID no. (1-50) has been assigned, the panel acts like Slave Panel Unit. It is dedicated to one
particular Chiller. It can only control the Chiller with same ID in the network.
Press [ESC] to exit to [Settings Menu].
13
