4) Compressor
C1 Min Run : 120s
C2 Min Stop : 240s
C3 2On Interval : 360s
C4 2Cp ON Dly : 15s
C5 P-Cp ON Dly : 60s
C6 Cp-P OFF Dly : 60s
C7 C
p
Cut Of
f
: 120ºC
5) Condenser Defrost
D1 Start Temp : -3ºC
D2 End Temp : 14ºC
D3 Max Dura : 10m
D4 Interval : 45m
D5 Dly Bfr Def : 0s
D6 Dly Aft Def : 0s
6) Cool Mode Antifreeze
A1 Heater SP :5ºC
A2 Heater Diff : 2.0ºC
A3 Sensor : Leave
A4 Alarm SP : 3ºC
A5 Alarm Diff : 2.0ºC
7) Alarm and Contact
P1 FS Confirm :5s
P2 FS Delay : 180s
P3 LP Delay : 30s
P4 CO Reset : Manual
P5 HP Rest : Auto
P6 LP Reset : Auto
P7 FO Reset : Manual :
P8 RO Reset : Manual
P9 FS Reset : Manual
P10 Aux Reset : Manual
P11 A/F Reset : Manual
P12 CO Contact : Normal
P13 HP Contact : Normal
P14 LP Contact : Normal
P15 FO Contact : Normal
P16 PO Contact : Normal
P17 FS Contact : Normal
P18 EA Contact : Normal
P19 DE Contact : Normal
Please refer to 8. APPENDIX for detail description.
