Cooling Only

Refrigerant: R 407C

MODEL

COOL COMP. COOL COMP. COOL COMP. COOL COMP. COOL COMP. COOL COMP. COOL COMP.

CAP. INPUT CAP. INPUT CAP. INPUT CAP. INPUT CAP. INPUT CAP. INPUT CAP. INPUT

kW kW kW kW kW kW kW kW kW kW kW kW kW kW

5 24.0 4.6 21.9 6.1 21.1 6.6 20.6 6.9 19.3 7.3 17.4 7.8 15.0 8.5

6 24.7 4.9 22.6 6.6 22.2 7.1 21.3 7.4 20.0 7.8 18.0 8.3 15.5 9.1

M4AC080C

7 24.9 5.1 23.0 6.9 22.3 7.5 21.7 7.8 20.4 8.2 18.6 8.7 16.1 9.5

8 25.2 5.5 23.2 7.3 22.6 7.9 22.0 8.2 20.8 8.6 18.7 9.1 16.2 9.9

9 26.0 5.9 23.6 7.9 23.1 8.5 22.6 8.8 21.4 9.2 19.1 9.7 16.5 10.5

10 26.6 6.4 24.3 8.5 23.4 9.1 23.0 9.8 22.1 9.8 19.8 10.3 17.2 11.2

5 26.5 5.2 25.5 7.2 24.9 7.8 24.5 8.2 23.2 8.7 21.6 9.2 18.9 10.0

6 27.3 5.6 26.3 7.7 26.1 8.4 25.3 8.7 24.0 9.2 22.3 9.8 19.5 10.6

M4AC100C

7 27.9 5.7 26.7 8.1 26.2 8.8 25.8 9.2 24.5 9.7 23.0 10.3 20.3 11.1

8 28.1 6.2 27.1 8.6 26.6 9.3 26.2 9.7 25.0 10.1 23.2 10.7 20.4 11.6

9 28.6 6.7 27.5 9.3 27.2 10.0 26.9 10.4 25.7 10.8 23.7 11.4 20.9 12.3

10 29.4 7.2 28.3 10.0 27.6 10.8 27.3 11.5 26.5 11.6 24.6 12.2 21.5 13.1

5 34.1 6.3 33.4 8.0 32.6 8.7 32.0 9.1 30.4 9.6 28.2 10.2 26.3 11.5

6 35.2 6.7 34.5 8.6 34.2 9.3 33.0 9.7 31.4 10.2 29.3 10.9 27.2 12.2

M4AC120C

7 35.5 7.1 35.0 9.0 34.3 9.8 33.7 10.2 32.0 10.7 30.2 11.4 28.0 12.9

8 36.2 7.5 35.5 9.5 34.8 10.3 34.2 10.7 32.7 11.2 30.4 11.9 28.3 13.3

9 36.8 8.0 36.1 10.3 35.6 11.1 35.2 11.5 33.7 12.0 31.1 12.7 28.9 14.2

10 37.8 8.7 37.1 11.1 36.1 11.9 35.7 12.8 34.7 12.8 32.2 13.5 29.9 15.0

5 42.5 7.6 41.3 9.5 39.6 10.4 38.2 10.9 37.0 11.5 34.9 12.3 31.8 14.0

6 43.8 8.2 42.6 10.3 41.5 11.1 39.4 11.6 38.2 12.2 36.1 13.0 32.9 14.8

M4AC150C

7 44.7 8.6 43.3 10.8 42.0 11.7 40.2 12.2 39.0 12.8 37.3 13.7 34.0 15.6

8 45.1 9.1 43.8 11.4 42.4 12.3 40.8 12.8 39.8 13.4 37.6 14.2 34.2 16.2

9 45.9 9.9 44.6 12.3 43.1 13.3 41.9 13.7 41.0 14.3 38.4 15.2 35.3 17.4

10 47.2 10.6 45.8 13.3 44.0 14.3 42.6 15.3 42.2 15.3 39.8 16.1 36.2 18.2

LEAVING WATER TEMP (°C)

28 32 35

AMBIENT TEMPERATURE (°C)

4219 4640

CH8-30 PUMP (120 & 150)

CH4-40 PUMP (080 & 100)
