Components Data

      
FAN
TYPE CENTRIFUGAL(BLADE:FORWARD)
QUANTITY 1 2 3 4
MATERIAL
GALVANIZED STEEL
DRIVE
DIRECT DRIVE
DIAMETER
mm 160
in 6.25
LENGTH
mm 200
in 7.875
MOTOR
TYPE SINGLEPHASECAPACITORRUNNING
QUANTITY 1 2
 IP20/E
COIL
TUBE
MATERIAL
COPPER
DIAMETER
mm 9.52
in 3/8
THICKNESS
mm 0.30
in 0.012
FIN
MATERIAL
ALUMINIUM
THICKNESS
mm 0.11
in 0.0043
FACE AREA
m
2
0.09 0.13 0.15 0.19 0.24 0.26 0.32
ft
2
0.98 1.35 1.64 2.07 2.62 2.84 3.41
ROW
C 3
H/F 4
FIN PER INCH
11
AIR
FILTER

TYPE NYLON/ALUMINIUMFRAME
SIZE
LENGTH
mm 462 632 762 962 1212 1311 1572
in 18.19 24.88 30.00 37.87 47.72 51.61 61.89
WIDTH
mm 205
in 8.07
THICKNESS
mm 8
in 0.31
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
