-17-
Design & installation Guide For McQuay MDS Multi System
1.6.5 Specification
Model Unit MDS030A MDS030AR MDS040A MDS040AR MDS050A MDS050AR MDS060A MDS060AR
Nominal cooling capacity kW 8.5 8.5 10 10 12.5 12.5 14.5 14.5
Nominal heating capacity kW - 9.0 - 11.5 - 13.5 - 16.5
Power supply 220V~/50Hz
Dimension Lx W x H mm
Weight
kg 82 85 112 115 117 120 123 130
Cooling rated power input
kW 3.0 3.0 3.5 3.6 4.4 4.4 5.0 5.0
Cooling rated current
A 13.6 13.6 15.9 15.9 20 20 22.8 22.8
Heating rated power input
kW - 2.5 - 3.4 - 4.2 - 4.2
Heating rated current
A - 11.4 - 15.5 - 19 - 20.3
Refrigerant
R22
Type of connecting pipe
copper f lare fitting & nipple joint
Liquid pipeф
(mm/in)
Gas pipeф
(mm/in)
Notes:
◆ The nominal cooling cap acity is gotten in the return air temperature of 27℃ /19℃ , and the ambient temperature of 35 ℃/24℃.
◆ The nominal heating capacity is gotten in the return air temperature of 20℃ /15℃ , and the ambient temperature of 7℃ /6℃.
◆ The specifications may be undated as we are trying to update the units at the time, please regard the nameplate of the unit as
standard.
840x408x900 1058x430x1044 1058x4230x1247
9.52(3/8
″
) 9.52(3/8
″
) 9.52(3/8
″
) 9.52(3/8
″
)
15.88(5/8″) 19.05(3/4″) 19.05(3/4″) 19.05(3/4″)
Notes:
◆ The nominal cooling cap acity is gotten in the return air temperature of 27℃/19℃ , and the ambient temperature of 35℃ /24℃
◆ The nominal heating capacity is gotten in the return air temperature of 20℃ /15℃ , and the ambient temperature of 7℃ /6℃ .
◆ The specifications may be undated as we are trying to update the units at the time, please regard the nameplate of the unit as
standard.
Connecting
accessory
pipe size
Model Unit MDS050A MDS050AR MDS060A MDS060AR
Nominal cooling capacity kW 12.5 12.5 15 15
Nominal heating capacity kW - 13.5 - 17
Power supply 380V/3N~/50Hz
Dimension L x W x H mm
Weight
kg 117 120 123 130
Cooling rated power input
kW 4.4 4.4 5.0 5.0
Cooling rated current
A 8.4 8.4 9.6 9.6
Heating rated power input
kW - 4.2 - 4.23
Heating rated current
A - 8.0 - 8.8
Refrigerant
R22
Liquid pipe
Gas pipe
Liquid pipe ф (mm/in)
Gas pipe ф (mm/in)
1
058x430x1044 1058x430x1247
Copper flare fitting & nipple joint
Copper flare fitting & nipple joint
9.52(3/8″)
19.05(3/4″)
Connecting
accessory
pipe size
Type of
connecting
pipe
To Next Page
