Design & installation Guide For McQuay MDS Multi System
Notes:
◆ The nominal cooling cap acity is gotten in the return air temperature of 27℃ /19℃ , and the ambient temperature of 35℃ /24 ℃
◆ The nominal heating capacity is gotten in the return air temperature of 20℃ /15℃ , and the ambient temperature of 7℃ /6℃.
◆ The sound level is gotten from the test room, it may differ in actual use due to the ambient temperature or
1.6.6 Specification
Model MDS080B MDS080BR MDS100B MDS100BR MDS120B MDS120BR MDS150B MDS150BR MDS180B MDS180BR MDS200B MDS200BR
Nominal cooling
kW 24.5 24.5 28.0 28.0 32.5 32.5 40.0 40.0 47.5 47.5 50.0 50.0
capacity
Nominal heating
kW - 26.0 - 30.0 - 34.0 - 43.0 - 50.0 - 53.0
capacity
Power supply 380V/3N～/50Hz
Sound leveldB(A) 62 62 64 64 66 66 67 67 66 66 66 66
Dimension Lx W x H mm 990x840x1840 1290x840x1840 1990x840x1840
Weight kg 275 290 285 300 290 305 355 370 520 550 560 590
Cooling rated
kW 7.5 7.5 8.5 8.5 9.8 9.8 12.9 12.9 14.1 14.1 15.2 15.2
power input
Cooling rated current A 14.6 14.6 16.8 16.8 18.8 18.8 23.1 23.1 28.2 28.2 31.1 31.1
Heating rated
kW - 7.2 - 8.3 - 9.0 - 11.1 - 13.2 - 14.7
power input
Heating rated current A - 13.6 - 15.7 - 16.7 - 22.6 - 27.1 - 29.4
Refrigerant R22
Gas side Welding & flange
Liquid side Flare fitting &nipple joint
Liquid pipe ф mm(in) 12.7(1/2) 15.88(5/8)
Gas pipe ф mm(in) 28.6(11/8) 34.9(13/8)
Model MDS220B MDS220BR MDS240B MDS240BR MDS260B MDS260BR MDS280B MDS280BR MDS300B MDS300BR
Nominal coolingcapacity
kW 55.0 55.0 65.0 65.0 70.0 70.0 75.0 75.0 80.0 80.0
Nominal heating capacity kW - 58.0 - 68.0 - 75.0 - 80.0 - 85.0
Power supply 380V/3N～/50Hz
Sound level dB(A) 66 66 68 68 68 68 69 69 69 69
Dimension Lx W x H mm 1990x840x1840 2280x840x1840 2580x840x1840
Weight kg 560 590 570 600 645 675 710 740 710 740
Cooling rated power input kW 16.7 16.7 19.8 19.8 21.3 21.3 22.8 22.8 26.2 26.2
Cooling rated current A 32.7 32.7 38.5 38.5 40.0 40.0 42.5 42.5 46.5 46.5
Heating rated power input kW - 16.2 - 18.5 - 20.9 - 22.0 - 23.6
Heating rated current A - 31.0 - 33.8 - 37.2 - 41.0 - 43.1
Refrigerant R22
Gas side Welding & flange
Liquid side Flare fitting &nipple joint
Liquid pipe ф mm(in) 19.05(3/4) 19.05(3/4)
Gas pipe ф mm(in) 38.1(11/2) 41.3(15/8)
Connecting
accessory
pipe size
pipe
size
