McQuay PDAE

IM 950-1 / Page 37 of 38
Model 007 009 012 015 017
PDHE (Packaged) 131.0 138.5 139.4 147.1 –
PDAE (Packaged) 129.5 137.0 137.9 145.6 145.6
PDHE (Chassis) 116.0 123.5 124.4 132.1 –
PDAE (Chassis) 114.5 122.0 122.9 130.6 130.6
Louvers
Flush-stamped ...............................................6 lbs. (3kg)
Architectural .................................................8 lbs. (3kg)
Subbase
3" (76mm) High Electrical .........................10 lbs. (5kg).
4" (102mm) High Electrical .....................12 lbs. (5.4kg)
8" (203mm) High Hydronic ........................20 lbs. (9kg)
Unit Weight - (lbs.)
