60 TGZ 040A through TGZ 190A OMM TGZ-1
VIEW REFRG Cir 2 (1)
Evap Press XXX.X psi
Cond Press XXX.X psi
VIEW REFRG Cir 2 (2)
Sat Evap XXX.X °
°°
°F
Sat Cond XXX.X °
°°
°F i
VIEW REFRG Cir 2 (3)
SuctionTemp=XXX.X°
°°
°F
Surperheat = XXX.X°
°°
°F
EvapApproach= XX.X°
°°
°F
TGZ Only (R134a)
VIEW REFRG Cir 2 (4)
LiqLineTemp=XXX.X°
°°
°F
Subcooling = XXX.X°
°°
°F
CondApproach= XX.X°
°°
°F
Units with EEV only
VIEW REFRG Cir 2 (5)
EXV Ctrl = XXX
EXV Pos = XXX.X%
SH Target = XX.X°
°°
°F
TGZ Units Only (R134a)
VIEW REFRG Cir 2 (6)
EXV Ctrl Range
XX.X% ---XX.X%
View Tow er
VIEW TOWER (1)
Stages ON = 1 of 2
EntCondTemp = XXX °
°°
°F
Setpoint = XXX °
°°
°F
The first Stages ON value is the number of fan stages ON. The second number is the Tower
Stages setpoint (0 if Tower Control = None). This screen shows the number of tower fans
“on” for each circuit. This screen will show the fans “on” whether they are actually
connected to and controlled by the MicroTech II controller or not.
