1.1. Manually Turning On and Off a Magnum Relay Output
Note: If a relay is in a Lockout state you cannot manually turn it on or off.
First, after logging into the Magnum with your authorization code
(see Appendix A), use the arrow keys to navigate to Outputs:
Next, use the up and down arrow keys to highlight the relay you want to
turn on or off:
Now press the Enter key. You should see something similar to the following:
09:56 Main Menu
-Status -Setpoints
-Outputs -Serv Tools
-Inputs -Lckout RST
-Alarms -Lckout ALM
-Graphs -Passwords
Help
09:56 Outputs 
Relays Status
M-1 COMP1-1 Off.
M-2 LOAD1-1 Off
M-3 UNLOD1-1 Off
M-4 LLS1-1 Off
Anlog .PG PG
09:56 Outputs 
Relays Status
M-1 COMP1-1 Off.
M-2 LOAD1-1 Off
M-3 UNLOD1-1 Off
M-4 LLS1-1 Off
Anlog . PG PG
COMP1-1
Manual AUTO ,
Status
