MCS MCS-Magnum User Manual

16
Appendix D (continued)
1.2. Sensor Input Reference Table
Sensor Type Reading
HUMD2
54.0%
LD1000 500p
M 50-KW 43.6K
M 75-KW 65.1K
M100-KW 86.6K
MCS 667 100.0P
MCS CO2 1001p
MCS-200 100.0P
MCS-500 100.0P
MCST100 77.0F
MCSX400 99.9P
MCSX500 99.9P
MEDIA-5 -99.9P
METER P -999p
PT 1000*
169.0F
PT100 213.1F
R22 PPM 500p
REF LVL 50%
ROSE300 113.0P
ROSE500 188.6P
RPM'S -999R
S FLW T -999%
S TMP T -999F
SAFMAG -99.9G
Sensor Type Reading
STAEFA -99.9”
STAT 50 23.5”
STAT CO2 -999p
STAT.25 -9.99”
STAT0.2 0.07”
STAT1 % 1233.6%
STAT1 F 1233.6%
STAT2 % 4.8%
STAT2 F -99.9F
STAT3 % -99.9%
STAT3 F -99.9F
STAT4 % -99.9%
STAT4 F -99.9F
STATIC.2ib 0.10”
STATIC1 -99.9”
STATIC3 -99.9”
STATIC5 1.8”
STATIC5iB 2.50”
T100LOW
.999p
TI-150 60.3P
TI-150A
75.0P
TI-2ACE 110.2A
TIACE17 190.8A
TONS 1DEC -99.9T
Sensor Type Reading
VAC-600 326.6V
