Use a exible brush to scrape the walls of the rebox (arrow 1 in the gure) so as to make the ash fall into the ash pan.
Use a vacuum cleaner nozzle to vacuum up any remaining ash and dust in the ash pan and brazier zone.
Repeatedly pass it between the exchangers pipes (arrow 2 in the gure) to remove the fuel deposits and residues.
With the product extracted,
remove the screws “z”, the plate
“P” and the gasket “O” at the
bottom and on the side and use
a vacuum cleaner to remove any
remaining ash residues. Before
putting the plate “P” back in
place, change the gasket “O”.
It is also advisable to vacuum
near to the coupling “r” and “k”
and remove and clean the smoke
fan “L”.
