MDC XT12 - Page 43

42
1300 4X4 4X4
48 MONTHS / 40,000KM SERVICE
CHECKED
Hitch Inspect for damage and lubricate. Check bolt Torque to 76Nm
Jockey Wheel Inspect for condition and operation
Hand winch Check brake function and webbing
Suspension Lubricate and check bushes for excess movement. Torque bolts to 190Nm
Brakes Inspect and adjust. Check lining thickness and drum wear
Wheel bearings
Replace bearings, seals and lubricate. Check stub axle condition and wear.
Replace split pin.
Wheel Nuts
Inspect condition and torque to 125Nm (12mm studs)
(140Nm 14mm studs alloy rims) (200Nm 14mm studs steel rims)
Tyres Inspect for abnormal wear, damage and pressure
Lights Check all lights are functioning
Battery Check terminals and voltage at full charge
Seals Check condition and correct latch/lock adjustment for correct 30-50% compression
General fixings Check all structural fixing are secure.
Hot Water Syst Descale hot water system
Date: Service Person:
Dealer Stamp:
54 MONTHS / 45,000KM SERVICE
CHECKED
Hitch Inspect for damage and lubricate. Check bolt Torque to 76Nm
Hand brake Check cable and adjust if necessary
Hand winch Check brake function and webbing
Suspension Lubricate and check bushes for excess movement. Torque bolts to 190Nm
Brakes Inspect and adjust. Check lining thickness and drum wear
Wheel bearings Remove, clean and re-lubricate. Inspect for wear and replace if necessary
Wheel Nuts
Inspect condition and torque to 125Nm (12mm studs)
(140Nm 14mm studs alloy rims) (200Nm 14mm studs steel rims)
Tyres Inspect for abnormal wear, damage and pressure
Gas System Leak, test, check stove operation and hose/coupling condition
Battery Check terminals and voltage at full charge
Seals Check condition and correct latch/lock adjustment for correct 30-50% compression
General fixings Check all structural fixing are secure.
Date: Service Person:
Dealer Stamp:
