Me2, Fog Generator
Operating Guide, Rev: A/a 12 / 30
The tree menu architecture is explained below. Items highlighted in blue are state menu ( - ), and
those highlighted in yellow are control menu ( ).
STATUS Status menu
STATE ---- Status State
UNIT OFF - the generator is off
xx% HEAT - the generator is heating, but not ready
PURGE - the generator is purging the heating module
READY - the generator is generator is ready to produce fog
FOG ON - the generator is producing Fog
FAIL - the generator is off, due to a failure (see diagnostic)
ERROR ---- Error message when State = FAIL (see diagnostic)
TEMP. ---- Temperature status (heating module)
TOO LOW - temperature too low
OK - temperature within specifications (ready)
TOO HIGH - temperature too high
PRESSURE xx.x Current reservoir pressure
PCB TEMP ---- Temperature of the board (see Units)
RUN TIME xx.x Total Run Time in decimal hours
FOG TIME xx.x Total Fog Time in decimal hours
LAST ERR yyyyy Code for the Last five (5) errors
See Fail State paragraph
CONTROL Control menu
UNIT ---- Unit toggle
OFF - the generator is off
ON - the generator is on
FOG ---- Fog toggle
OFF - the fog is off
ON - the fog is on
SET PRES. xx.x Fog operating pressure (see Units)
