Me2, Fog Generator
Operating Guide, Rev: A/a 13 / 30
INTERFACE Network /DMX/RDM Menu
COMM. ---- Communication toggle
AUTO - the generator is controlled by DMX/RDM if a signal is
present, or locally if there is no signal
LOCAL - the generator is controlled by the keyboard ONLY
DMX - the generator is controlled by DMX/RDM ONLY
DEV LABEL yyyyyy RDM Device Name
DEV ID yyyyyy RDM Device ID
DMX ADDR yyy DMX Address (1 to 510) Network / DMX / RDM
1 UNIT yyy Channel #1 value: OFF
50% (128)
ON
2 OUTPUT yyy Channel #2 value: 0% (0) to 100% (255)
3 FOG yyy Channel #3 value: OFF
50% (128)
ON
SETTINGS Settings menu
UNITS ---- Units toggle
PSI/°C - pressure in psi, temperature in Celsius
kPA/°C - pressure in kPa, temperature in Celsius
BAR/°C - pressure in bar, temperature in Celsius
PSI/°F - pressure in psi, temperature in Fahrenheit
LCD SAVER ---- LCD Saver Mode
30 s - LCD saver is activated after 30 s
2 mn - LCD saver is activated after 2 min
OFF - LCD Saver is Off
VERSION x.xx Model Version
FIRMWARE x.xx Program Firmware
