MDS

• 3.3V Power output

• Output → Good, Fail indicate signal (active “L”)

• Input → Start Key (active “L”)

6-1. E-PGM+ / E-PGM Serial handler connection

E-PGM+

Handler

Start

Good

Fail

+3.3V

GND

Common

Handler Cable connector

MOLEX Part Number: 50-37-5023 (SD-5264-05)

2.50mm Pitch SPOX™ Wire-to-Board Crimp Housing, Friction Lock, 2 Circuits
