DC20D MK2 GENSET CONTROLLER USER MANUAL
6
 Low Oil Pressure Stop
 High water temperature stop
 Oil pressure sensor Open
 Water temperature sensor Open
 Start Failure
 Stop Failure
 Low Water level stop
 Low Water level stop
 High Oil temperature stop
 RPM signal lost alarm
 Over speed stop
 Under speed stop
 Low Fuel Level warning
 Low Battery voltage warning
5. Parameters
Options
Parameters
Working voltage
DC8V----36V Continuous
Power consumption
Standby：24V：MAX 1W
Working：24V：MAX 3W
AC Voltage Input
1P2W 30VAC-276VAC (ph-N)
Rotate speed sensor
Frequency
30-9999Hz
MAX Accumulating Time
99999.9Hours（Min Store time:6min）
Fuel Relay Output
Max 5 Amp DC+VE Supply voltage
Start Relay Output
Max 5 Amp DC+VE Supply voltage
AUX. OUTPUT 1
Max 2.5 Amp DC+VE Supply voltage
AUX. OUTPUT 2
Max 2.5 Amp DC+VE Supply voltage
Excitation output
Max 1AMP DC+VE supply voltage
Switch value input
Available if connecting with Battery -
Working condition
-25-65℃
Storage condition
-40-85℃
Protection Level
IP54：when waterproof rubber gasket is added
between controller and its panel
Insulation strength
Apply AC1.5kV voltage between high voltage terminal
and low voltage terminal; The leakage current is not
more than 3mA within 1min.
Overall dimension
78mm*78mm*55mm
Panel cutout
67mm*67mm
Weight
0.3Kg
